18. Orient the Rear Console Cover (80) as shown.

Attach the Rear Console Cover (80) to the

Upright (4) with two M4 x 16mm Screws (101).

Next, orient the Front Console Cover (79) as

shown.

Attach the Front Console Cover (79) around the

Upright (4) by pressing the hooks on the Rear

Console Cover (80) onto the tabs on the Front

Console Cover.

101

73, 74

17. Orient the Shield Cover Cap (11) and the Shield

Cover (75) as shown.

First, press the tabs on the Shield Cover Cap

(11) into the Left and Right Shields (73, 74).

Then, press the tabs on the Shield Cover (75)

into the Left and Right Shields (73, 74).

19. Make sure that all parts are properly tightened before you use the elliptical. Extra parts may be included.

Place a mat beneath the elliptical to protect the floor.
