Radio Operations
21
MAX983HD
English
Owner’s manual
DX Seek:
Touch the [k] or [K] key to automatically
seek a station.
When the [K] key is touched, the station is
sought in the direction of higher frequencies;
if the [k] key is touched, the station is sought
in the direction of lower frequencies.
• When the DX Seek tuning starts, “DX Seek”
appears on the Information pane.
LO Seek:
If you keep touching the [k] or [K] key more
than 1 second, the Local Seek tuning is
carried out.
The broadcast stations with good reception
sensitivity are automatically selected.
• When the Local Seek tuning starts, “LO
Seek” appears on the screen.
Manual tuning
There are 2 ways available: Quick tuning and
step tuning.
When you are in the step tuning mode, the
frequency changes one step at a time. In quick
tuning mode, you can quickly tune the desired
frequency.
1. Select the desired band by touching the
[Band] key.
2. Touch and hold the [Band] key for more than
1 second to switch to the manual tuning
mode.
“Manual” appears on the screen, and the
manual tuning is now available.
3. Tune into a station.
Quick tuning:
Touch and hold the [K] or [k] key for more
than 1 second to tune in a station.
Step tuning:
Touch the [K] or [k] key to manually tune in
a station.
Recalling a preset station
There are total of 24 preset positions (6 FM1, 6
FM2, 6 AS, 6 AM) to store individual radio
stations in memory.
There are 3 ways available to recall the preset
station.
● From the Tuner mode screen
1. Select the desired band by touching the
[Band] key.
2. Touch the desired Preset key on the Preset
key pane to recall the preset station.
● From the AV Shortcut menu
1. Select the desired band by touching the
[Band] key.
2. Touch [P.ch] keys to tune in the previous or
next preset station.
• You can also use the [R] and [F]
(Search) buttons instead of the [P.ch] keys.
Manual memory
1. Select the desired band by touching the
[Band] key.
2. Select the desired station with the seek
tuning, manual tuning, or preset tuning.
3. Touch and hold one of the Preset key for more
than 2 seconds to store the current station into
the preset memory.
