INSTALLATION AND WIRE
CONNECTION MANUAL
Wire connection notes
CAUTION
• Connect cables appropriately. If a wrong
connection is made, this may cause a fire or
accident.
• When passing cables through the body of
the vehicle, use non-conductive grommets.
• If the coatings of the cables are worn out by
rubbing, this may cause an accident, fire or
a short circuit.
• After wiring cables, fix them with insulation
tape.
• Be sure to switch off the vehicle when
connecting or disconnecting cables to/from
the unit, otherwise an electric shock, injury
or accident may occur.
WARNING
• Loom all cables according to the
instruction manual so as not to hinder
operation.
• Wire the connecting cables away from
high temperature areas. If the coatings of
the cables melt, it may cause an accident/
fire by a short circuit. Take care when
wiring in the engine compartment.
• When wiring the connecting cables in a
vehicle with an airbag system, never feed
the cables through a place where it may
interfere with the operation of the airbag.
If the airbag not operating correctly in an
emergency, it may cause increased
injury.
