GRAPHITE 58G505 [12/100] Detailed safety regulations

TRANSLATION OF THE ORIGINAL INSTRUCTIONS

ROTARY HAMMER DRILL

58G505

CAUTION: BEFORE USING THE POWER TOOL READ THIS MANUAL CAREFULLY AND KEEP IT FOR FUTURE

REFERENCE.

DETAILED SAFETY REGULATIONS

Ɣ Use ear protection when operating the rotary hammer drill. Noise hazards may cause hearing loss.

Ɣ Use protection measures for respiratory system when operating the rotary hammer drill. Dust ha-

zards may cause respiratory system illness.

Ɣ Use dust extraction systems whenever required by the nature of the work performed.

Ɣ Use additional handles supplied with the tool. Loss of control may cause operator personal injury.

CAUTION! This device is designed to operate indoors.

The design is assumed to be safe, protection measures and additional safety systems are used, ne-

vertheless there is always a small risk of operational injuries.

CONSTRUCTION AND USE

Rotary hammer is a hand-operated power tool with insulation class II. The tool is driven by single-phase

commutator motor with rotational speed reduced with gear transmission. Rotary hammer can be used for

drilling holes in working modes with impact or rotation only. Range of use covers repair and building works,

woodworking and any work from the scope of individual, amateur activities (tinkering).

Use the power tool according to the manufacturer’s instructions only.

DESCRIPTION OF DRAWING PAGES

Below enumeration refers to the device elements depicted on the drawing pages of this manual.

1. SDS-PLUS chuck

2. Fixing sleeve

3. Switch lock button

4. Switch

5. Operation mode switch

6. Additional handle

7. Depth gauge rod

8. Direction selector switch

* Dierences may appear between the product and drawing

MEANING OF SYMBOLS

CAUTION

WARNING

ASSEMBLY/SETTINGS

INFORMATION

EQUIPMENT AND ACCESSORIES

1. Drills - 1 pce

2. Depth gauge rod - 1 pce

3. Additional handle - 1 pce

4. Drill chuck + key - 1 pce

5. Chuck adapter - 1 pce

6. Grease container - 1 pce

7. Transport case - 1 pce
