GRAPHITE 58G791 [12/68] Operation and maintenance

Switching on – press the switch button (6) and hold in this position.

Switching o – release pressure on the switch (6).

Locking the switch (continuous operation)

Switching on:

Ɣ Press the switch button (5) and hold in this position (g. A).

Ɣ Press the switch lock button (4).

Ɣ Release pressure on the switch button (5).

Switching o:

Ɣ Press and release the switch (6).

Rotational speed of the spindle is controlled with pressure on the switch button (6). Screwdriver

transmits drive to the working bit only after it is pressed against processed material or a screw head.

LEFT  RIGHT DIRECTION OF ROTATION

Choose direction of the screwdriver spindle rotation with the direction selector switch (6) (g. B).

Right rotation – move the switch (6) to the extreme right position.

Left rotation – move the switch (6) to the extreme left position.

* The possibility is reserved that in certain cases position of the switch relating to rotation direction may be diﬀerent than

speciﬁed. Please refer to graphic signs placed on the switch or tool body.

Do not change direction of rotation when the spindle of the screwdriver is rotating. Ensure the

position of the selector switch is correct before starting the tool.

SCREWING DEPTH CONTROL

With control ring (2) you can set up the depth of the screw head sinking into material.

Ɣ Set required screwing depth by turning the control ring (2) (g. C).

- turning clockwise – increases the screwing depth

- turning counter-clockwise – decreases the screwing depth.

It is best to set correct screwing depth by test screwing in waste material. Screw is held by universal

magnetic holder. Press the screw tip against material it is to be screwed into until the depth limiter reaches

the material, and the screwing tip disconnects. To unscrew screws set the switch lever (6) to the extreme

left position.

SCREWDRIVER BODY HOOK

Screwdriver body hook (3) is very useful when working, during breaks it allows to hang the screwdriver e.g.

on a tool belt.

OPERATION AND MAINTENANCE

Unplug the power cord from the mains socket before commencing any activities related to

installation, adjustment, repair or maintenance.

Screwdriver does not require any additional lubrication or special maintenance. There are no user

serviceable parts inside the tool.

Never use water or other chemical liquids for cleaning the screwdriver. Wipe the tool with a dry cloth.

Always keep the screwdriver in a dry place.

Always keep the ventilation holes on the screwdriver body pervious.

In case of power cord damage replace it with a cord with the same speciﬁcation. Entrust the repair to a

qualiﬁed specialist or take the screwdriver to a service shop.

CARBON BRUSH REPLACEMENT

Replace immediately worn out (shorter than 5 mm), burnt or cracked motor carbon brushes with the

new ones. Always replace both brushes at a time.

Entrust replacement of carbon brushes only to a qualiÿed person. Only original parts should be used

All faults should be repaired by service workshop authorized by the manufacturer.

GRAPHITE 58G791 [12/68] Operation and maintenance
