Chicago Pneumatic CP3451-18SEC [2/2] Cp3451 series model d

Index

Part

Description Qty

37 6153071550 Rear body safety lever type 1

38 6156721530 Plug 1

39 6153120940 Valve stem 1

40 6153212370 Lever 1

41 6156350380 Pin spring 3x20 1

42 6156583030 O-Ring 6x2.65 1

43 6156583000 O-Ring 14x1.8 1

44 6156583040 O-Ring 11.2x2.65 1

45 6156583020 O-Ring 36x1.8 1

46 2050541503 Grid 1

47 6155041890 Guard 2,5" 1

48 6155041910 Guard 3" 1

49 6155020800 Front ange 2,5" 1

50 6156080440 Nut HEX H M10 1

51 6155020790 Front ange 3" 1

52 6155701000 Rear sleeve 1

53 6155700980 Front sleeve 1

55 2050543883 Exhaust foam 1

56 2050547503 Noise reduction foam 1

57 2050546543 Air inlet (rotative lever type) 1

80 6154320110 Exhaust hose (not shown) 1

81 2,050,496,453 Wrench not shown 2

82 6158010810 Stem 1

6158727840 Warning Label die-grinder 1

6158727860 Warning Label grinder 1

TUNE UP KIT

6153973030 (Including Parts No: 5, 8, 10, 13, 46)

BLADES KIT (50 pcs)

6154340650

Index

Part

Description Qty

1 6154001460 Cylinder 1

2 6154201430 Front plate 1

3 6154261180 Rotor 1

4 6156611030 Washer 1

5 2050547623 Rotor Blade (set of 4) 1

6 6154221590 Rear plate CP3451-16 1

7 6154221600 Rear plate CP3451-18 1

8 6157581380 Bearing 8x22x7 608Z 1

9 6156731330 Motor end cap 1

10 6157510100 Bearing 10x30x9 6200 1

11 6156350370 Pin spring 4

12 6153212340 Pressing cover 1

13 6156582970 O-Ring 11.8x1.8 1

14 6155011230 Spindle CP3451-18SEC Series 1

15 6155652970 Extension Housing 1

16 6156071560 Front nut Die -grinder 1

17 6155011240 Spindle CP3451-XXSE3 - SER3 - SE25 1

18 6157580970 Bearing 10x22x6 61900ZZ 2

19 6156300280 Key CP3451-XXSE3 - SER3 - SE25 1

20 6155421330 Adapter for cone wheel

(accessory inclueded CP3451-SEC)

21 6155230250 Collet holder 1

22 6155260630 Collet 1/4" 1

23 6156071540 Collet nut 1

24 6156071550 Front nut (grinder) 1

25 6155031620 Rear Flange 3"

26 6155031610 Rear ange 2,5"

27 6153071570 Rear housing rotative throttle

28 6153120950 Valve stem

29 6156700560 Plug

30 6156811440 Switch spring

31 6156582990 O-Ring 12.5x1.8

32 6153071590 Rotate switch 1

33 6157440310 Filter 1

34 6156890390 Ring snap RW35 1

35 6156583010 O-Ring 30x1.8 1

36 6157301880 Exhaust hose adaptor (rotative type) 1

2050543753 EC declaration

6159948760 Safety instructions grinder

6159948750 Safety instructions die grinder

6159948640 Operator's manual grinder

6159948650 Operator's manual die grinder

Recommended accessories

Silencer hose Kit

6154320110

Exhaust hose adaptor

6157301870

(required for safety lever type)

Overhose

2050547523

CP3451 Series -Model D

Grinder

2050543783 Rev 03

03/2016

Spare parts without part number are not sold separately
