Gazer F140 [16/50] Mount installation

Viewing records/Mount installation

Mount installation

1. Prior to installing the MVR, please, degrease the windshield surface. Then

attach the MVR frame to the mount.

2. Mount the MVR on the windshield.

3. Lay the power cable as shown in the drawing.

4. Loosen the screw by turning it counterclockwise. Adjust the DVR position on

the mount and set the desired shooting direction. Secure the DVR in place

by turning the screw clockwise.

• To access the video viewing menu, rst stop the current

recording with the REC/OK button and then press the

MODE/MICROPHONE button to switch to the viewing mode. Use

UP/DOWNbuttonstonavigatethroughvideolesandpressthe

REC/OK button to start or pause video playback. In the «viewing»

mode, the MENU button is responsible for photo and video les

managementsubmenu(deletingandprotectingthecurrentleor

alllesonthememorycard).UsetheMODE button to exit from the

viewingmode.Whenyounishviewing,donotforgettore-enable

the recording function by pressing the REC/ОК button.
