Mount installation

Recommendation: Install your MVR as high as possible (MVR

frame right next to the rear view mirror or behind it) in the

position in which the lens is directed slightly downward at an

angle of about 15°. If the MVR is set too low (on the dashboard

or a bit higher), the recorded videos will not provide full

information about the road situation as it is impossible to see the

front of your vehicle. Therefore, there is no «reference point».

Recordings will be signicantly dimmed if the device is set in

parallel with the road or at an upward angle.

Connecting power to the mount

The MVR mount supports power connection, which allows using the

mount to supply power to the device. To connect power to the

mount, follow the steps shown in the drawing 6.

To detach the MVR from the mount, please, follow the steps shown

in drawing. To detach the MVRfrom the mount,rst pressthe tab (1).

With the tab still pressed, detach the MVR from the mount by sliding it to

the side (2).

5 6
