ENG

Preparing MVR

One needs to precongure the MVR before using it. By default

(factory settings), all main parameters are set to optimal values.

Nonetheless, one still needs to set the exact time and date. This is

required for further analysis of recorded video les.

Make sure that all indicators are turned off and then insert the

memory card into the corresponding slot without connecting the

МVR to a power source. The memory card must be inserted with

contacts facing the screen.

Connect the MVR power adapter to a 12V car cigarette lighter

socket and supply power. Once turned on, the MVR automatically

switches to the recording mode. Therefore, the rst thing you will

see on the screen will be real-time video feed from the camera

(point-to-point channel) and the recording mode indicator.

Mainwindowiconsdenition

3. To access the МVR settings menu, you rst need to stop the

recording by pressing the OK button (15) (the recording stops

with some delay because the device needs to close and save the

le with the last video clip) and then press the MENU button (5).

4. Use «Up» (3) and «Down» (8) buttons to navigate the menu, OK

button (15) – to access submenus and select parameters, MENU

button (5) – to exit from the menu.

GPS status

(for Gazer F150g)

WDR

Cycle Recording

Power/Battery

Indicator

Recording resolution

Recording Mode

(Video/Time-Lapse/Photo)

Date and Time

Current recording

location

(for Gazer F150)
