Sharp MX-M1204 [4/19] Transit and delivery

MX-M1204 MX-M904/M1054/M1204 (MAIN UNIT) 2 – 3

2. Transit and delivery

A. Implements, facility, and manpower

A forklift is recommended for removing the machine from the ship-

ping carton.

If no forklift is available, Be sure to use the skid slope (DKIT-

0367FCZZ). Removing the machine by hand requires four or more

persons as the machine is heavy. Use care and safety precautions

when removing the machine from the shipping carton.

Transit of the machine must be made in a protected and secure

condition to the place of install.

Since the hard disk drive is built in the machine, refrain from vibra-

tions or shocks to the machine when in transit.

B. Delivery

Remove the packing materials prior to installation in the office envi-

ronment.

When delivering the machine, be sure to keep the separation pawl

fixing material attached. (If the machine is delivered without the fix-

ing material, the drum may be scratched.)

NOTE: For USA / CANADA

If the fusing performance is insufficient in a special environment

such as low temperature and low humidity, an environment that

heavy paper is mainly used and so on when 208V power supply is

used, please replace with 208V lamp (RLMPU0764FCPZ).

(Measurement method)

Measure the voltage between L and N of the figure above using a

digital multi meter.

3. Unpacking

A. Pulling out the main unit

1) Remove the top case, the top cushion, the packing case, and

the box containing the operation panel, the operation panel

arm and parts for assembly.

2) Cut the four corners of the bottom case.

No Content Method

1 Implements, facility,

and manpower

Use a forklift. (If no forklift is available,

ensure manpower of four persons or more,

and use the skid slope (DKIT-0367FCZZ)).

2 Delivery Transit must be made in safely packed and

protected environment.

GND

Voltage reference points for wall outlet.
