1
UV
2
A stands for Ultraviolet-induced Multi-domain Vertical Alignment, a photo-alignment technology that ensures
uniform alignment of liquid crystal molecules. *
2
Analogue PC, video, and component video are switchable (on bottom
interface); use the menu to select. Video and component video connections require conversion cable via mini D-sub
15-pin jack. *
3
For connecting keyboard, mouse, and USB memory device.
VISION
SPECIFICATIONS
Model PN-70TB3 PN-60TB3
Installation Landscape
LCD Panel
70-inch-class (176.6 cm diagonal)
UV
2
A*
1
LCD
60-inch-class (152.5 cm diagonal)
UV
2
A*
1
LCD
Max. Resolution 1,920 x 1,080 pixels
Max. Display
Colours (approx.)
1.06 billion colours
Pixel Pitch (H x V) 0.802 x 0.802 mm 0.692 x 0.692 mm
Brightness*
1
300 cd/m
2
Contrast Ratio 3,000 : 1
Viewing Angle (H/V) 160°/160° (CR ≥10)
Active Screen Area
(W x H)
1,538.9 x 865.6 mm 1,329.1 x 747.6 mm
Response Time 6 ms (grey to grey, avg.)
Backlight LED, edge lit
Computer
Input
Video Analogue RGB (0.7 Vp-p) [75], DisplayPort 1.1
Synchronisation
Horizontal/vertical separation (TTL: positive/negative), Sync on green
(D-sub 15-pin only), Composite sync (TTL: positive/negative)
Plug & Play VESA DDC2B
Power Management VESA DPMS, DVI DMPM
Video Colour System NTSC (3.58 MHz, 4.43 MHz), PAL, PAL60, SECAM
Input Terminals*
2
PC analogue: Mini D-sub 15-pin x 2*
2
, HDMI (HDCP and 1080p
compatible, PC/AV signal compatible) x 3, 3.5 mm-diameter mini stereo
jack x 2, Video x 1*
2
, Component video x 1*
2
Output Terminals*
3
3.5 mm-diameter mini stereo jack x 1,
DisplayPort (HDCP compatible) x 1
Input/Output Terminals LAN port (10Base-T/100Base-TX) x 1
Built-in Speakers Built-in - 10 W + 10 W, External - 10 W + 10 W
Power Supply 100V – 240V AC, 50/60 Hz
Power Consumption 250 W 185 W
Environmental
Conditions
Operating Temperature 5˚C to 35˚C
Operating Humidity 20% to 80% RH (no condensation)
Dimensions (W x D x H) (approx.)
(display only)
1,647 x 94 x 1,010 mm 1,437 x 94 x 890 mm
Weight (approx.) 61 kg 46 kg
11
