SPECIFICATIONS
47
Model PN-R556 PN-R496 PN-R426
Installation Landscape / Portrait / Face-up / Face-down
LCD Panel
55-inch widescreen
(138.78cm diagonal)
TFT LCD
49-inch widescreen
(123.20cm diagonal)
TFT LCD
42-inch widescreen
(106.47cm diagonal)
TFT LCD
Max. Resolution 1,920 x 1,080 pixels
Max. Display
Colours (approx.)
1.07 billion colours
Pixel Pitch (H x V) 0.630 x 0.630 mm 0.559 x 0.559 mm 0.483 x 0.483 mm
Brightness*
1
700 cd/m
2
Contrast Ratio 1,300 : 1
Viewing Angle (H/V) 178°/178° (CR ≥10)
Active Screen Area
(W x H)
1,209.6 x 680.4 mm 1,073.8 x 604.0 mm 927.94 x 521.96 mm
Response Time 8 ms (grey to grey, avg.)
Backlight LED, edge lit
Computer
Input
Video
Analogue RGB (0.7 Vp-p) [75Ω], Digital (DVI 1.0 standard–compliant),
DisplayPort 1.2, HDMI
Synchronisation
Horizontal/vertical separation (TTL: positive/negative), Sync on green*
2
,
Composite sync (TTL: positive/negative)*
2
Plug & Play VESA DDC2B
Power Management VESA DPMS, DVI DMPM
Input Terminals*
3
DisplayPort x 1, DVI-D 24-pin (HDCP compatible) x 1, Mini D-sub
15-pin x 1, HDMI (PC/AV signal compatible) x 2, RS-232C x 1,
3.5 mm-diameter mini stereo jack x 1
Output Terminals*
3
DisplayPort x 1, 3.5 mm-diameter mini stereo jack x 1, RS-232C x 1
Input/Output Terminals*
3
LAN: 10Base-T/100Base-TX x 1
Power Supply Terminal
5 V, 2 A (5V, 500 mA when the expansion slot is used)
(USB type-A connector)
Expansion Slot
12V, 2.4 A (power supplied when expanding the functions with an
optional part)
Built-in Speakers 10 W + 10 W
Mounting VESA (4 points), 400 mm pitch, M6 screw
VESA (4 points), 200
mm pitch, M6 screw
Power Consumption 175 W 155 W 135 W
Environmental
Conditions
Operating
Temperature*
4
0°C to 40°C
Operating Humidity 20% to 80% RH (no condensation)
Dimensions (W x D x H) (approx.)
(display only)
1,231 x 57 x 702 mm 1,095 x 57 x 626 mm 949 x 57 x 543.5 mm
Weight (approx.) 25 kg 19.5 kg 15.5 kg
Main Accessories
AC power cord, remote control unit, battery (AAA size x 2), CD-ROM,
set-up manual, cable clamp x 2, ceiling mounting bracket x 4, ceiling
mounting bracket fixing screw x 4, logo sticker
*
1
Brightness depends on input mode and other picture settings. Brightness level will decrease slightly over the
lifetime of the product. Due to the physical limitations of the equipment, it is not possible to maintain a precisely
constant level of brightness. *
2
D-sub input terminal only. *
3
Use a commercially available connection cable for PC and
other video connections. *
4
When using the monitor laying flat on a surface (when the monitor is tilted 20 degrees
or more upward or downward from the perpendicular in relation to a level surface) the ambient temperature must
be within the range of 0°C to 30°C. Temperature condition may change when using the monitor together with the
optional equipment recommended by Sharp. In such cases, please check the temperature condition specified by the
optional equipments.
