EN 11
Using a PC
Communication Procedure
Send the control commands from the PC via the
RS-232C or IP.
The TV operates according to the received command
and sends a response message to the PC.
Do not send multiple commands at the same time.
Wait until the PC receives the OK response before
sending the next command.
Command format
Eight ASCll codes +CR
Command 4-digits Parameter 4-digits Return code
C1 C2 C3 C4 P1 P2 P3 P4
Command 4-digits: Command. The text of four
characters.
Parameter 4-digits: Parameter 0-9, x, blank, ?
Parameter
Input the parameter values, aligning left, and fill with
blank(s) for the remainder. (Be sure that 4 values are
input for the parameter.)
When the input parameter is not within an adjustable
range, "ERR" returns. (Refer to "Response code
format".)
Any numerical value can replace the "x" on the table.
— 3 0
0009
0
????
?
When "?" is input for some
commands, the present
setting
value
responds.
Response code format
Normal response
Return code (0DH)
O K
Problem response
(communication error or incorrect command)
Return code (0DH)
E R R
Command table
• Commands not indicated here are not guaranteed to operate.
*1 For RS-232C only.
You can use "Wake On LAN (Magic Packet)" to turn on the power via LAN. It is not possible to turn on the monitor with the IP Control command.
CONTROL ITEM COMMAND PARAMETER CONTROL CONTENTS
POWER ON
COMMAND SETTING
R S P W 0 _ _ _ Off The Power On command rejected.
1 _ _ _ On [RS-232C] The Power On command accepted.
2 _ _ _ On [IP] The Power On command accepted.
POWER SETTING P O W R 0 _ _ _ Power Off It shifts to standby.
1 _ _ _ Power On Power On
*1
INPUT
SELECTION
TOGGLE I T G D x _ _ _ (Toggle) It input-switches by the toggle. (It is the same as
an input change key.)
1-6 I A V D * _ _ _ 1: HDMI IN1, 2: HDMI IN 2,
3: HDMI IN 3, 4: VIDEO IN 1,
5: COMPONENT/VIDEO IN 2,
6: PC IN
AV MODE SELECTION A V M D * _ _ _ 0: (Toggle), 1: STANDARD,
2: MOVIE,
4: USER, 5: DYNAMIC (Fixed),
6: DYNAMIC
,
7: PC
Although it can choose now, it is toggle operation
in inside.
VOLUME V O L M * * * _ Volume (0-100)
POSITION H-POSITION H P O S * * * _ (-50-50) For PC input.
The screen position variable ranges depend on
the View Mode or the signal type. The ranges can
be seen on the position-setting screen.
V-POSITION V P O S * * * _ (-50-50)
CLOCK C L C K * * * _ (0-100)
PHASE P H S E * * _ _ (0-63)
VIEW MODE W I D E * * _ _ 0: (Toggle) [AV],
1: Side Bar [AV],
2: S.Stretch [AV],
3: Zoom [AV],
4: Stretch [AV, USB-Video,
Home Network Video or
Internet applications],
5: Normal [PC],
7: Stretch [PC],
8: Dot by Dot [PC] [AV],
9: Full Screen [AV],
10: Auto [USB- VIdeo, USB-Photo, Home
Network Video, Photo or Internet applications],
11: Original [USB-Video, USB-Photo, Home
Network Video, Photo or Internet applications]
0: Although it can choose now, it is toggle
operation in inside.
1: Only available when 4:3 signal is being input.
5: Only available when 4:3 signal is being input.
8: [PC] Available except when UXGA is being
input.
[AV] Only available when 1080i/p is being input.
9: Only available when 720p is being input.
10, 11: Available when USB-Video,
USB-Photo,
Home Network Video, Photo or
Internet application is used.
MUTE M U T E * _ _ _ 0: (Toggle), 1: On, 2: Off
SURROUND A C S U * _ _ _ 0: (Toggle), 1: On, 2: Off
AUDIO SELECTION A C H A x _ _ _ (Toggle)
SLEEP TIMER O F T M * _ _ _ 0: Off,
1: OFF TIMER - 30 MIN., 2: OFF TIMER - 60 MIN.,
3: OFF TIMER - 90 MIN., 4: OFF TIMER - 120 MIN.
CC C L C P x _ _ _ (Toggle) Toggle operation of a closed caption.
DEVICE NAME T V N M 1 _ _ _ The device name set in "Device Name" is
displayed.
MODEL NAME M N R D 1 _ _ _ The model name of the Monitor
SOFTWARE
VERSION
S W V N 1 _ _ _ The current version of the Monitor software is
displayed.
IP PROTOCOL
VERSION
I P P V 1 _ _ _ The currently supported version of IP protocol is
displayed.
REMOTE CONTROL
BUTTONS
R C K Y * * _ _ 0-9: 0-9, 10: DOT, 12: POWER, 13: DISPLAY, 23: OPTION, 24: SLEEP, 31: MUTE, 32: VOL -,
33: VOL +, 34: CH
, 35: CH , 36: INPUT, 38: MENU, 40: ENTER, 41:
a
, 42:
b
, 43:
a
, 44:
a
,
45: RETURN, 46: EXIT, 49: AUDIO, 50: A (red), 51: B (green), 52: C (blue), 53: D (yellow), 61: MANUAL
NOTE
• If an underbar (_) appears in the parameter column, enter a space.
• If an asterisk (*) appears, enter a value in the range indicated in brakets under CONTROL CONTENTS.
• Any numerical value can replace the "x" on the table.
