• Utilisation : sawing with sprinkling of
fresh, old or coated (asphalt) concrete.
• Tools : Water-cooled diamond-
impregnated discs - Øx350 mm - bore
25.4 mm.
(Details from your usual supplier).
1
Use
10
Switch off the disk prior to moving
the machine on jobsite.
Remove the disk prior to hoisting,
loading, unloading and transporting
the machine on jobsite.
SPECIAL INSTRUCTIONS
The disc cutter is designed to provide safe
and reliable service in operating conditions
corresponding with the instructions, but it
can present dangers for the user and risks
of damage, consequently regular on site
inspection is necessary to ensure :
• Perfect technical condition (use for
the purpose for which it is intended
and taking into account any risks, and
correction of any malfunction
detrimental to safety).
• Use a diamond disk for cutting with
water (sawing new or old concrete,
tarmac or asphalt). No other type of
disk is allowed (abrasive, saw, etc...).
• Competent staff (qualifications, age,
training) who have read and
understood the manual in detail
before starting work: any electrical,
mechanical or other problem should
be investigated by a qualified
maintenance engineer (electrician,
maintenance manager, approved
dealer, etc . . .).
• That the warnings and instructions
marked on the machine are followed
(adequate personal protection,
correct use, general safety
instructions, etc).
• That no modification, transformation
or addition is detrimental to safety
and that it is carried out without prior
authorization from the manufacturer.
• Respect of the maintenance intervals
and periodical checks recommended.
• That only genuine spare parts are
used for repairs.
FAILURE TO COMPLY WITH
THESE WARNINGS COULD
RESULT IN DEATH OR SERIOUS
BODILY INJURY.
3
Description of the machine [FIG. 1]
11. Handle
12. Motor stop
13. Lowering handwheel
14. Graduated scale
15. Engine
16. Engine oil drain
17. Front guide
18. Belt cover
19. Disk casing
10. Service spanner
11. Water intake tap
12. Tank (17 litres)
4
Handling - Transport
Height of adjustable handlebars
(unscrew the lever (M))
[
SEE FIG. 2].
• The ground-saw only needs pushing to
move it into position on the site. It is easy
to move on its four wheels, without
starting the motor.
• The handwheel (K) locks the machine
itself in the high position.
• Light weight, compact, transportable in a
vehicle by one person.
MANDATORY
INDICATION
INFORMATION
INSTRUCTION
WARNING
PROHIBITION
These signs give advice
concerning your safety
DO carefully read and understand all the
instructions before operating the saw.
DO always keep all guards in place.
DO aways wear safety approved hearing,
eye, head and respiratory protection.
DO keep all parts of your body away from
the blade and all other moving parts.
DO know how to stop the saw quickly in
case of an emergency.
DO shut off the engine and allow it to cool
before refueling.
DO inspect the blade, flanges and shafts
for damage before installing the
blade.
DO use only blades marked with a
maximum operating speed greater
than the blade shaft speed.
DO use caution and follow the
instructions when loading and
unloading the saw.
DO NOT allow other persons to be near
the saw when starting, refueling
or when cutting.
DO NOT operate gasoline engines in an
enclosed area unless it is
properly vented.
DO NOT use damaged equipment or
blades.
DO NOT operate the saw in areas of
combustible material. Sparks
from the saw could cause a fire
or an explosion.
DO NOT allow blade exposure from the
guard to be over 180 degrees.
DO NOT leave the saw unattended with
the motor running.
DO NOT operate the saw while under the
influence of drugs or alcohol.
This symbol indicates that the
machine is in conformance with
the applicable European directive.
DO
DO NOT
English
TYPETYPE SERIAL
POWER
VOLTAGE
FREQUENCY
INTENSITY
FABRICATION
YEAR
WEIGHT
MAXI TOOL
BORE
SPEED
MANUFACTURER
MASSE UTILE Kg
mm
mm
Ø MAXI OUTIL.
Ø ALESAGE
T/MN - RPM
N° SERIE
ANNEE DE
FABRICATION
PUISSANCE kW
Hz
V
A
PLAGE DE
TENSION
FREQUENCE
INT. UTIL.
Instruction plate
