1 PRODUCT DESCRIPTION

TI970 thermostat is intended for controlling oor heating cables. The thermostat

is programmable and it regulates the temperature of a room or oor automatically

according to dened or measured temperature values. Temperature values can be

set between +5°C and +40°C degrees. When wood is selected as oor material,

temperature values can be set between +5°C and 27°C degrees.

Read the operation and installation instructions carefully before installing and using

the thermostat. Remember to store the installation and operation instructions for

later use.

TI970 has an internal room sensor and an external oor sensor. The used sensor

can be selected through the setting menus of the thermostat (oor sensor must

be connected). The thermostat can be set in either Automatic, Personal, Manual,

LP, ECO or Power regulation modes. Primary function of the Automatic mode is

to lower the temperature at times of day and night when the user does not require

a higher temperature for comfort. This way it is possible to save energy. Default

program settings are listed in table 1. The default setting is suitable for most

conditions. When Personal mode is activated, you can create customized daily

schedules to minimize energy consumption and maximize comfort. There can be

up to ve set points per day. The manual mode is used to override the automatic

and personal modes, whereupon only one set temperature is in continuous use. LP

mode is a special mode for laminated and parquet oors which prevents damage

to the oor when heating is switched ON. ECO mode reduces energy costs to

a minimum. Power regulation is used to switch the oor heating ON and OFF

following a percentage value within 30 minutes window.

2 INSTALLATION

Installation must be done by a qualied electrician in accordance with wiring and

building regulations. Before installation, disconnect any power to the thermostat’s

mains. During installation of the thermostat, power to the thermostat must be

disconnected or isolated AT ALL TIMES!

Start by carefully releasing the front cover by pushing the release snaps, which are

located in the center on both the left hand and the right hand side. Use e.g. a small

slotted screwdriver. The front cover and the frame can now be removed. Please

see picture below.

Now connect the wires to the thermostat’s terminals:

1. HEATING (N): Heating Cable connection (Neutral)

2. N: Power connection (Neutral)

3. L: Power connection (Live)

4. HEATING (L): Heating Cable connection (Live)

5-6. SENSOR: Floor temp sensor NTC type
