TECHNICAL DATA
Mitre saw MTF216/1100T MTF250/1500T
Absorbed power W 1100 1500
No-load speed / min 5000 4300
Cut at 90º/mitre (AxB Fig.4 a) mm 58x133 70x150
Cut at 45º/mitre (AxB Fig.4 b) mm 58x90 70x85
Cut at 90º/blade at 45º (AxB Fig.4 c) mm 35x1330 47x150
Cut on upper bench mm 31,5 45
Upper bench dimensions mm 224х358 264х385
Blade diameter mm 216 250
Blade hole diameter mm 20(30) 20(30)
Weight Kg 9,5 11
Overall dimensions (LxHxW) mm 427x277x531 460х450х300
Acoustic pressure, Lpa dBA 96 92
Sound power emitted, Lwa dBA 109 105
Vibration level (according to ISO 8041 and ISO 5348) m/sec2 2,5 3,9
Carefully observe the instructions in this manual, keep it in a safe
place at hand for any possible checks on the parts indicated.
If the tool is used with care and a normal maintenance is carried
out, it will have a long life.
GENERAL INFORMATION
DENTIFICATION (See indicated gures)
A Saw penetration adjustment screw (Fig.1a)
B Uptake connection nozzle (Fig.1,1a)
C Pushbutton switch (Fig.1)
D Safety hook release button (Fig.1)
E Switch lock button (Fig.1)
F Upper bench saw protector (Fig.3)
G Upper bench (Fig.1,1a)
H Upper bench blocking handles (Fig.2)
I Saw blade (Fig.1,2)
J Mobile guard (Fig.1)
K Turntable (Fig.1)
L Base (Fig.1,3)
M Fixed guide (Fig.1)
O Motor unit blocking lever (Fig.1)
P Position lock pin (Fig.1a)
Q Fixed saw protection, extractable (Fig.1а)
Q1 Protection button (Fig.1,1a)
R Scale index (Fig.1)
R1 Graduated scale for turning the motor unit (Fig.1)
R2 Graduated scale turntable (Fig.1)
S Guide xing buttery (Fig.1,2)
T Upper bench guide (Fig.1,3)
V Handles (Fig.3) (Optional accessory)
Y Bench xing bolt (Fig.1) (internal)
Z1 Adjustment bolt (Fig.1a)
Z2 AC cable (Fig.1)
Z3 Brush holder cover (Fig.1)
Z4 Clamp (Fig.5) (Optional accessory)
TECHNICAL CHARACTERISTICS
The robust and highly reliable structure makes these mitres
suitable for cutting wood, aluminium and steel in industrial
environments, while preserving their usual ease of handling and
without restricting their movement.
The MTF216/1100T and MTF250/1500T are tted with a wide
upper table that allows the mitre saw to be transformed into a
table saw to carry out cutting (up to a thickness of 45 millimetres).
The MTF216/1100T and MTF250/1500T are tted with two
working tables (upper and lower), and have been provided with a
switch to keep the circuit on while pressing, and a lock-on button
for free-hands operation when working on the upper bench.
The MTF216/1100T and MTF250/1500T are tted with a
new electronic device to prevent the machine from starting
unexpectedly after a break in the voltage supply. When this
happens, to restart you must oper-ate the switch to switch-off
and then to switch-on.
A single operator is needed to use the mitre saw, of which the
design and construction comply with stan-dards EN 61029-1 and
EN 60204-1.
SAFETY DEVICES
• Atrest,thebladeistotallycoveredbytwoprotec-tors,
one xed and one mobile, which are automati-cally opened by
the descent of the blade unit when cutting.
• On the upper bench, the blade is covered by one protection
