English | 17
Bosch Power Tools 1 609 92A 36W | (8.6.16)
Product Description and Specifica-
tions
Read all safety warnings and all instruc-
tions. Failure to follow the warnings and in-
structions may result in electric shock, fire
and/or serious injury.
While reading the operating instructions, unfold the graphics
page for the machine and leave it open.
Intended Use
The machine is intended for lengthways and crossways cut-
ting of wood with straight cutting lines as well as mitre cuts in
wood while resting firmly on the workpiece.
The light of this power tool is intended to illuminate the power
tool’s direct area of working operation and is not suitable for
household room illumination.
Product Features
The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.
1 Lock-off button for On/Off switch
2 Worklight
3 Hex key
4 Auxiliary handle (insulated gripping surface)
5 Spindle lock button
6 Base plate
7 Wing bolt for parallel guide
8 Wing bolt for bevel-angle preselection
9 Scale for mitre angle
10 Cutting mark, 45° (0° on GKS 18V-57 G)
11 Cutting mark, 0° (45° on GKS18V-57G)
12 Parallel guide
13 Retracting blade guard
14 Lever for retracting blade guard
15 Wing bolt for bevel-angle preselection
(GKS 18V-57 G)
16 Chip ejector
17 Blade guard
18 On/Off switch
19 Battery pack*
20 Handle (insulated gripping surface)
21 Saw spindle
22 Mounting flange
23 Saw blade*
24 Clamping flange
25 Clamping bolt with washer
26 Battery unlocking button*
27 Fastening screw for extraction adapter*
28 Extraction adapter*
29 Clamping lever for cutting-depth preselection
30 Cutting-depth scale
31 Set of screw clamps*
32 Button for charge-control indicator*
33 Battery charge-control indicator*
34 Guide rail*
35 Vacuum hose*
36 Connection piece*
*Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.
Technical Data
Circular Saw GKS 18 V-57 G GKS 18 V-57
Article number
3 601 FA2 1.. 3 601 FA2 2..
Rated voltage
V= 18 18
No-load speed
min
-1
3400 3400
Cutting depth, max.
–for 0° bevel angle
–for 45° bevel angle
mm
mm
57
42
57
39
Spindle lock
For use with FSN guide rail system
–
Base plate dimensions
mm 252 x 194 188 x 138
Saw blade diameter
mm 165 165
Blade thickness, max.
mm 1.7 1.7
Blade thickness, min.
mm 1.0 1.0
Tooth thickness/setting, max.
mm 2.6 2.6
Tooth thickness/setting, min.
mm 1.7 1.7
Mounting bore
mm 20 20
* depending on the battery pack being used
** Limited performance at temperatures <0 °C
OBJ_BUCH-2769-003.book Page 17 Wednesday, June 8, 2016 9:35 AM
