10
• Changing bits 9
- insert the bit as deep as possible in the chuck
! do not use bits with a damaged shank
• Adjusting drilling depth 0 (6270/6280)
• Holding and guiding the tool !
! while working, always hold the tool at the
grey-coloured grip area(s)
- always use auxiliary handle F 2 (can be adjusted
as illustrated) (6270/6280)
- keep the ventilation slots uncovered
- do not apply too much pressure on the tool; let the tool
do the work for you
APPLICATION ADVICE
• Use the appropriate bits @
! only use sharp bits
• For drilling in concrete or stone a steady pressure on the
drill is required
• When drilling ferrous metals
- pre-drill a smaller hole, when a large hole is required
- lubricate drill bit occasionally with oil
• When turning in a screw at/near the cross cut end or an
edge of wood, pre-drill a hole in order to avoid cracking of
the wood
• Splinterfree drilling in wood #
• Dustfree drilling in walls $
• Dustfree drilling in ceilings %
• Drilling in tiles without skidding ^
• For more tips see www.skileurope.com
MAINTENANCE / SERVICE
• Always keep tool and cord clean (especially ventilation
slots H 2)
! disconnect the plug before cleaning
• If the tool should fail despite the care taken in
manufacturing and testing procedures, repair should be
carried out by an after-sales service centre for SKIL
power tools
- send the tool undismantled together with proof of
purchase to your dealer or the nearest SKIL service
station (addresses as well as the service diagram of
the tool are listed on www.skileurope.com)
ENVIRONMENT
• Do not dispose of electric tools, accessories and
packaging together with household waste material
(only for EU countries)
- in observance of European Directive 2002/96/EC on
waste of electric and electronic equipment and its
implementation in accordance with national law,
electric tools that have reached the end of their life
must be collected separately and returned to an
environmentally compatible recycling facility
- symbol & will remind you of this when the need for
disposing occurs
DECLARATION OF CONFORMITY
• We declare under our sole responsibility that this product
is in conformity with the following standards or
standardized documents: EN 60745, EN 61000,
EN 55014, in accordance with the provisions of the
directives 2006/95/EC, 2004/108/EC, 2006/42/EC
• Technical file at: SKIL Europe BV (PT-SEU/PJE),
4825 BD Breda, NL
Arno van der Kloot
Vice President
Operations & Engineering
SKIL Europe BV, 4825 BD Breda, NL
Jan Trommelen
Approval Manager
28.02.2011
NOISE/VIBRATION
• Measured in accordance with EN 60 745 the sound
pressure level of this tool is 93 dB(A) and the sound
power level 104 dB(A) (standard deviation: 3 dB), and the
vibration ✱ (hand-arm method; uncertainty K = 1.5 m/s²)
✱ when drilling in metal 5.4 m/s²
✱ when impact drilling in concrete 13.7 m/s²
• The vibration emission level has been measured in
accordance with a standardised test given in EN 60 745;
it may be used to compare one tool with another and as a
preliminary assessment of exposure to vibration when
using the tool for the applications mentioned
- using the tool for dierent applications, or with dierent
or poorly maintainted accessories, may signicantly
increase the exposure level
- the times when the tool is switched o or when it is
running but not actually doing the job, may signicantly
reduce the exposure level
! protect yourself against the effects of vibration
by maintaining the tool and its accessories,
keeping your hands warm, and organizing your
work patterns
Perceuse
à percussion 6002/6270/6280
INTRODUCTION
• Cet outil est conçu pour les travaux de perçage en frappe
dans la brique, le béton et dans la pierre naturelle ainsi
que le perçage dans le bois, le métal, la céramique et les
matières plastiques; les outils avec réglage électronique
de la vitesse et rotation à droite/à gauche sont également
appropiés pour le vissage et le letage
• Lisez et conservez ce manuel d’instructions 3
SPECIFICATIONS TECHNIQUES 1
