11

English

GB

BS 12G BS 14G BSB 12G BSB 14G

Drilling capacity in steel ........................................................................10 mm................10 mm...................10 mm ......................10 mm

Drilling capacity in steel (with chuck 1,5 - 13 mm) ................................. - ......................13 mm..................... - .............................13 mm

Drilling capacity in wood .......................................................................30 mm................32 mm...................30 mm ......................32 mm

Drilling capacity in wood (with chuck 1,5 - 13 mm) ................................- ......................32 mm..................... - .............................32 mm

Drilling capacity in brick and tile ............................................................. - ........................- ...........................6 mm ........................8 mm

No-load speed, 2nd gear (Li-Ion) ............................................................- .............. 0-1500 min

-1

................... - ......................0-1500 min

Rate of percussion under load max. ........................................................- ........................- .................. 20 250 min

-1

............. 21 000 min

Rate of percussion under load max. (Li-Ion) ........................................... - ........................- ........................... - ...................... 22 500 min

Torque * ................................................................................................30 Nm ................32 Nm ...................30 Nm .......................32 Nm

Torque * (Li-Ion) ......................................................................................- ......................36 Nm ..................... - .............................36 Nm

Battery voltage .....................................................................................12 V .................14,4 V .......................12 V........................14,4 V

Drill chuck range ............................................................................... 1-10 mm............1-10 mm............... 1-10 mm ...................1-10 mm

Sound pressure level (K=3dB(A)) .........................................................90 dB(A) ............90 dB(A) ..............90 dB(A) ................. 90 dB(A)

Sound power level (K=3dB(A)) ..........................................................101 dB(A) ..........101 dB(A) ............101 dB(A) ............... 101 dB(A)

Wear ear protectors!

Total vibration values (vector sum in the three axes) determined according to EN 60745.

Vibration emission value a

The declared vibration emission level represents the main applications of the tool. However if the tool is used for dierent applications, with

dierent accessories or poorly maintained, the vibration emission may dier. This may signicantly increase the exposure level over the total

working period.

An estimation of the level of exposure to vibration should also take into account the times when the tool is switched o or when it is running

but not actually doing the job. This may signicantly reduce the exposure level over the total working period.

Identify additional safety measures to protect the operator from the eects of vibration such as: maintain the tool and the accessories, keep

the hands warm, organisation of work patterns.
