www.aquafilter.com
FCPS20
FCCA
AICRO
TFC-75F
20 micron sediment filter traps dirt, sediment, rust and other
particulate matter.
Reverse Osmosis Membrane
Thin Film Composite
(75 GPD), 0.0001 micron
Semi-permeable membrane will remove salts, minerals, metals,
bacteria, viruses, cysts, TDS, Hardness, Fluorides, Pesticides,
Lead, Mercury, Cadmium & Arsenic and more. Due to the time needed
to remove all these ingredients your RO system includes a storage tank.
Sediment Pre-Filter
Spun-bounded polypropylene
Post-Carbon Filter
GAC activated carbon
Post Carbon Filtration granular activated coconut shell
carbon cartridge provides the final polishing and
assures good tasting drinking water
NOTE
- Do not use with water that is microbiologically unsafe or of unknown quality without adequate disinfection before or after the system.
- Water filtration systems can help reduce the presence of contaminants. In addition, some water filtration systems can help reduce the presence of microorganisms or other contaminants with potential health effects.
- We strongly recommend regularly scheduled maintenance and replacement of the filter cartridge in order for the product to perform properly.
- Replace the filter cartridge at least every 3 or 6 months (depending on water quality).
- RO membrane recommended to change every 2.5 -3 years (depending on water quality).
- Replace AICRO post RO membrane cartridge every 1 year (depending on water quality).
LIMITED WARRANTY: Manufacturer warrants that this product is free from defects in materials and workmanship. This warranty, together with any and all warranties implied by law, shall be limited to a period of two (2) years from the date
of original purchase.
This limited warranty does not apply to failures that result from abuse, misuse, alteration or failure to properly comply with installation, or cartridge change instructions.
We strongly recommend adding to all point of use filtration systems a Pressure Limiting Valve (PLV-0104 series) to guard against unwanted extreme water pressure events pressure increases, surges, and water hammer which could occur
in the water pipes. Not having one installed could mean that if you ever did have to claim damage caused by a burst water filter system, the claim will be denied.
CATALOG#
STAGE
COMPONENT FUNCTION
RX55145516
5 Stage Reverse Osmosis System
2
2
3
3
1
1
4
4
5
5
Specifications:
System dimensions: (H x W x L): 400 x 150 x 450 (mm)
Tank dimensions: (H x D): 380 x 280 (mm)
Connection adapter: 1/2”
Working Temp.: 2°C - 45°C (35º F - 113º F)
Operating Pressure: Max. 6.0 bar (90 psi) Min. 2.8 bar (40 psi)
Typical Rejection Rate: 98% TDS (Total Dissolved Solids)
pH Parameters: Maximum 11 Minimum 2
Iron: Maximum 0.2 ppm
TDS (Total Dissolved Solids) < 1800 ppm
Turbidity < 5 NTU
Tubing: Polyethylene 1/4”
Tank Capacity: 15 liters
Additional accessories
FXFCH17-C
Filter faucet
with ceramic valve
EG14WWAQ-4
10” filter housing
H10A series
FCPS5
10” melt-blow polypropylene
filter cartridge 5 µm
FCCBL
10” carbon
block cartridge
FCCA
10” GAC
cartridge
AICRO
in-line coconunt
shell carbon cartridge
AIMIAO2_K
Leak detection sensor
PLV-0104-80
Pressure limiting valve
AQCWW-W
Quick connectors
wrench
FXWR1-BL
Wrench
NI-212-CENT_AB
Antibacterial and Antimicrobial
Filter Cartridge Centralizing Ring
TFC-75F
Reverse Osmosis
Membrane
OR-N-630X40
Top and bottom
O-ring for the
membrane housing
The package contains:
- The RX55145516 comes complete with the following cartridges:
FCPS5, FCCA, FCCBL, AICRO
- RO membrane element type: TFC-75F Manufactured
by AQUAFILTER
- 3.2 Gallons Plastic Water Storage Tank (capacity 15 liters)
- NSF certified, Filter Housing (double o'ring)
- Automatic Shut-off Valve, Mini Flow Restrictor, Check Valve
- Long Reach Chrome Faucet: FXFCH17-C
- Feed water connector: 1/2”
- Drain Saddle Valve, Filter housing wrench
- Four Color Coded 1/4 inch Tubing for System Connection
- System built with quick type fittings
- Completely Assembled
- Manual instructions
- Color box
100% Factory Tested and Sterilized Ready for Installation
All Aquafilter images, trademarks, logos, and other intellectual property are the sole and exclusive property of Aquafilter, Inc. and may not be used without our express written permission.
Aquafilter
Manufacturing
Facility
Aquafilter Inc.
Hunt Valley 21030, USA
us@aquafilter.com
Aquafilter Europe
91-222 Lodz, Poland
pl@aquafilter.com
Aquafilter Germany
15234 Frankfurt, Germany
de@aquafilter.com
OR-N-880X40
NBR top O-ring
for the housings
H10B, H10C,
H10K,H105 series
OR-N-900X35
NBR bottom O-ring
for the housings
H10B, H10C,
H10K, H105 series
Carbon Cartridge
Activated coconut
shell carbon (GAC)
Coconut shell carbon reduce chlorine, color, odor
and other organic impurities
FCCBL
Carbon Cartridge Pre-Filter
Extruded activated carbon
Carbon block filter is used to reduce chlorine, color, odor
and other organic impurities
