E – 18
A43539,Russia R3471K O/M,EN
Disconnect the power supply cord before cleaning or leave the door open to inactivate the oven
during cleaning.
CLEAN THE OVEN AT REGULAR INTERVALS - Keep the oven clean and remove any food deposits, or it
could lead to deterioration of the surface. This could adversely affect the life of the appliance and possibly result in
a hazardous situation.
Exterior:
The outside may be cleaned with mild soap and warm water, wipe clean with a damp cloth. Avoid the
use of harsh abrasive cleaners. Keep the ventilation openings and power supply plug free of dust.
Door:
Wipe the door and window on both sides, the door seals and adjacent parts frequently with a damp cloth
to remove any spills or spatters. Do not use abrasive cleaners.
Touch control Panel:
Wipe the panel with a cloth dampened slightly with water only.
Do not scrub or use any sort of chemical cleaners. Avoid the use of excess water.
Interior walls:
To clean the interior surfaces, wipe with a soft cloth and warm water. After use wipe the waveguide
cover in the oven with a soft damp cloth to remove any food splashes. Built-up splashes may
overheat and begin to smoke or catch fire. Do not remove the waveguide cover. DO NOT USE A
COMMERCIAL OVEN CLEANER, ABRASIVE OR HARSH CLEANERS AND SCOURING PADS ON
ANY PART OF YOUR MICROWAVE OVEN. NEVER SPRAY OVEN CLEANERS DIRECTLY ONTO ANY
PART OF YOUR OVEN.
Avoid using excess water. After cleaning the oven, ensure any water is removed with a soft cloth.
Turntable/Roller Stay:
Wash with mild soapy water and dry thoroughly.
SERVICE CALL CHECK
Check the following before calling service:
1. Does the display light up? YES _______ NO _______
2. When the door is opened, does the oven lamp come on? YES _______ NO _______
3. Place one cup of water (approx. 250 ml) in a glass measuring cup in the oven and close the door
securely. Oven lamp should go off if door is closed properly.
Programme the oven for one minute on HIGH. At this moment:
A. Does the oven lamp come on? YES _______ NO _______
B. Does the cooling fan work? YES _______ NO _______
(Put your hand over the rear ventilation openings.)
C. Does the turntable rotate? YES _______ NO _______
(The turntable can rotate clockwise or counterclockwise. This is quite normal.)
D Does COOK indicator light up? YES _______ NO _______
E. After one minute, did an audible signal sound and COOK
indicator go off? YES _______ NO _______
F. Is the water inside the oven hot? YES _______ NO _______
If “NO” is the answer to any of the above questions, please check your wall socket and the fuse in your meter box.
If both the wall socket and the fuse are functioning properly, CONTACT YOUR NEAREST SERVICE
CENTER APPROVED BY SHARP.
NOTE: 1. If time in the display is counting down rapidly, check Demonstration Mode.
(Please see page E-17 for detail.)
2. If you cook the food over 40 minutes on HIGH power, the microwave power will be
automatically reduced to avoid overcooking.
SPECIFICATIONS
AC Line Voltage : Single phase 220V, 50Hz
Distribution line fuse/circuit breaker : Minimum 16A
AC Power Required : 1.6 kW
Output Power : 1100 W* (IEC test procedure)
Microwave Frequency : 2450 MHz (class B/Group 2)**
Outside Dimensions : 520mm(W) x 310mm(H) x 448mm(D)
Cavity Dimensions : 353mm(W) x 213mm(H) x 387mm(D)***
Oven Capacity : 29 liters (1.0 cu.ft)***
Cooking Uniformity : Turntable (ø320mm tray) system
Weight : Approx. 16 kg
* This measurement is based on the International Electrotechnical Commission’s standardised
method for measuring output power.
** This is the classification of ISM (Industrial, Scientific and Medical) equipment described in the
International Standard CISPR11.
*** Internal capacity is calculated by measuring maximum width, depth and height.
Actual capacity for holding food is less.
CARE AND CLEANING
SHARP CORPORATION OSAKA, JAPAN
TINSRA009WRRZ-Z41
Russia R3471K,En,P09-18 04.11.11, 5:03 PM18
