E – 7
A35652,Russia R217E O/M,En
A35652,Russia R217E O/M,En
SPECIFICATIONS
AC Line Voltage Single phase 220V, 50Hz
AC Power Required 1.16 kW
Output Power 800 W* (IEC test procedure)
Microwave Frequency 2450 MHz** (Class B/Group 2)
Outside Dimensions 460mm(W) x 290mm(H) x 372mm(D)
Cavity Dimensions 314mm(W) x 228mm(H) x 329mm(D)***
Oven Capacity 24liters (0.8 cu.ft)***
Cooking Uniformity Turntable (ø295mm tray) system
Weight Approx. 14 kg
* This measurement is based on the international Electrotechnical Commission's standardised method for
measuring output power.
**
This is the classification of ISM (Industrial, Scientific and Medical) equipment described in the International Standard CISPR11.
*** Internal capacity is calculated by measuring maximum width, depth and height.
Actual capacity for holding food is less.
CARE AND CLEANING
CLEAN THE OVEN AT REGULAR INTERVALS
Disconnect the power supply cord before cleaning or leave the door open to inactivate the oven during
cleaning.
Exterior:
The outside may be cleaned with mild soap and warm water, wipe clean with a damp cloth. Avoid the use of harsh abrasive cleaners.
Door:
Wipe the door and window on both sides, the door seals and adjacent parts frequently with a damp cloth to
remove any spills or spatters. Do not use abrasive cleaner.
Control Panel:
Wipe the panel with a cloth dampened slightly with water only.
Do not scrub or use any sort of chemical cleaners. Avoid the use of excess water.
CAUTION : Take care not to move the light up dial from "0" (off) position during cleaning, or the oven will
start as soon as you close the door.
Interior walls:
To clean the interior surfaces, wipe with a soft cloth and warm water for hygienic reasons. After use wipe the
waveguide cover in the oven with a soft damp cloth to remove any food splashes. Built-up splashes may
overheat and begin to smoke or catch fire. Do not remove the waveguide cover. DO NOT USE A COMMERCIAL
OVEN CLEANER, ABRASIVE OR HARSH CLEANERS AND SCOURING PADS ON ANY PART OF YOUR
MICROWAVE OVEN. NEVER SPRAY OVEN CLEANERS DIRECTLY ONTO ANY PART OF YOUR OVEN.
Avoid using excess water. After cleaning the oven, ensure any water is removed with a soft cloth.
Turntable/Roller Stay:
Wash with mild soapy water and dry thoroughly.
SERVICE CALL CHECK
Please check the following before calling for service:
Place one cup of water (approx. 250 ml) in a glass measure in the oven and close the door securely.
Cook the water for two minutes on HIGH power.
A. Does the oven lamp light? YES _______ NO _______
B. Does the cooling fan work? YES _______ NO _______
(Put your hand over the rear ventilation openings.)
C. Does the turntable rotate? YES _______ NO _______
(The turntable can rotate clockwise or counterclockwise. This is quite normal.)
D. After two minutes, did an audible signal sound? YES _______ NO _______
E. Is the water inside the oven hot? YES _______ NO _______
If “NO” is the answer to any of the above questions, please check your wall socket and the fuse in your meter box.
If both the wall socket and the fuse are functioning properly, CONTACT YOUR NEAREST SERVICE CENTRE
APPROVED BY SHARP.
NOTE: If time in the display is counting down rapidly, check Demonstration Mode. (See page E-6 for detail.)
