Laser lines

Features

1. Adjusting legs

2. Fine adjustment screw

3. Switch On handle (compensator lock)

4. Vertical laser window

5. Horizontal laser window (360°)

6. keypad

7. Battery compartment

8. Hole for chareger connection

9. Thread 5/8'' / Plumb down

Keypad

1. Button to switch Horizontal laser (H)

2. Button to switch Vertical lasers (V)

3. Detector mode

4. Power indicator

Operation

1. Place the instrument on the tripod or oor. When using tri-

pod, place the instrument on the tripod and screw the center-

ing screw into the center hole.

2. Switch On the instrument by rotating the switch (3). Power

indicator (4) lights up.

3. If there is a sound signal and laser lines begin to blink while

switching on the instrument, that means that the instrument is

out of range more than ±3°. Adjust the position of the instru-

ment by means of the bubble level with the help of legs or

tripod.

4. Aim the down point on the required point on the oor. Ro-

tate the upper part of the instrument to adjust vertical lines.

Then adjust the position of the instrument with the help of ne

adjustment screw (2).

5. Laser level has several operating modes. Press button 1

and 2 to select horizontal and vertical lines.

Variants of projections:

- 1vertical plane and down point;

- 2 vertical planes, down point;

- 4 vertical planes, down point.

Horizontal and vertical lines can work separately from each other.

Use the detector function when working with horizontal and
