4.2.1.1.1.1.65

4.2.1.1.1.1.66 • Dimensions

Width/depth/height

48  32.8 (30.7*)  41.5 in (1221  830 (790*)  1055 mm)

* without exhaust hose connection on the back of the machine and open top lid

Weight

Approx. 595 - 628 lbs (ca. 270 - 285 kg) – depending on laser power

Ambient conditions

Mandatory ambient temperature +15° C to +25° C or 59° F to 77° F

Humidity 40% to max.. 70%, not condensing

Dust-free environment (2nd degree according to IEC 60947-1)

4.2.1.1.1.1.68 • Laser safety

4.2.1.1.1.1.69

Laser class

CDRH laser safety; CE tested

Laser class 2

Interlock

Duplicate interlock safety system

Loading lid

Front-side loading lid

4.2.1.1.1.1.70 • Extraction System

Minimum volume required

(without piping/tubing)

300 m³/h bei 1.700 Pa (without multifunctional table concept)

350 m³/h bei 3.500 Pa (with multifunctional table concept)

Two connections DN 2.95 in (75 mm)

Required

Without multifunctional table concept:

Atmos Mono/Mono Plus, Vent 3000 (or equivalent systems; for surface

extraction)

Without multifunctional table concept: :

Atmos Duo Plus, Vent HP (or equivalent systems; for surface and table

extraction)

4.2.1.1.1.1.71 • Electrical Equipment

4.2.1.1.1.1.72

Power consumption

Approx. 1.2 to 1.9 kW (depending on laser power)
