SpeedMarker 300
8037 | V 2.1_EN (01/2016)
23/ 51
Data sheet
Laser
Laser
Q-Switched Yb-fiber laser, maintenance free
Wavelength
1064 nm ± 8
Pulse duration
110 ns ± 20
Beam quality
M² < 1,5
Power stability
better ± 5%
Cooling
air cooled
Laser type
FL 10
FL 20
FL 30
FL 50
Max. average output power
10 W
20 W
30 W
50 W
Max. pulse energy
0,5 mJ
1 mJ
1 mJ
1 mJ
Pulse repetition rate
20-80 kHz
20-80 kHz
30-80 kHz
50-80 kHz
Integrated pilot laser
Galvo-System
Standard:
F-160
Lens / Focal length
F-100
F-254
Marking area [mm x mm]
70 x 70
120 x 120
190 x 190
Focus diameter
~ 27 µm
~ 45 µm
~ 68 µm
Writing speed
(Option high-speed scan head)
640 cps – 1 mm single line with F = 160 mm
(900 cps – 1 mm single line with F = 160 mm)
Positioning speed
(Option high-speed scan head)
10.000 mm/s with F = 160 mm
(15.000 mm/s with F = 160 mm)
