SIM2 xTV Screen [3/4] 100 110

SIM2 xTV Screen [3/4] 100 110
PRODUCT DETAILS
PRODUCT NAME
Standard
SIM2x92 SIM2x100 SIM2x110
IMAGE SIZES
Display surface size
92” 100” 110”
Aspect ratio 16:9 16:9 16:9
IMAGE AREA
Width mm • inch 2,037 • 80.2 2,214 • 87.2 2,435 • 95.9
Height mm • inch 1,146 • 45.1 1,245 • 49.0 1,370 • 53.9
OUTER DIMENSIONS
(INCLUDING FRAME) and
WEIGHT
Width mm • inch 2,057 • 81.0 2,234 • 87.9 2,455 • 96.7
Height mm • inch 1,166 • 45.9 1,265 • 49.8 1,390 • 54.7
Display Surface (net) kg • lbs 11 • 24 12 • 26 14 • 31
SHIPPING
DIMENSIONS
(Space-saving design:
surface rolls up)
and WEIGHT
Display surface box
length
mm • inch 2,330 • 91.7 2,330 • 91.7 2,773 • 109.2
Display surface box
width
mm • inch 370 • 14.6 370 • 14.6 370 • 14.6
Display surface box
height
mm • inch 160 • 6.3 160 • 6.3 160 • 6.3
Box shipping weight kg • lbs 19 • 42 20 • 44 23 • 51
GENERAL DETAILS INCLUDED IN THE PACKAGE: Display surface, wall mounting accessories, installation manual
Peak gain Horisontal
half-gain angle
L
ens pitch Frame Width Frame Depth Environment
temperature
Humidity
(non-condensing)
0.50 85° 300 micron 10 mm 30 mm 10-40° C 10-70 %RH
ADVANCED OPTICAL TECHNOLOGY INSTALLATION PRINCIPLE
Black/White Lenticular Technology
This technology involves a triangular,
black, horizontal lenticular structure,
which is coated with reflecting material
on the side facing the SIM2xTV display.
The black topside of the reflector ab-
sorbs ambient light from above, while
light from the projector is reflected or
diffused by the white coating and sent
towards the audience. Best image con-
trast is achieved when the SIM2xTV is
below or above the display surface and
the reflector is pointing downwards.
1
White reflector
2
Black linticular lens
3
Substrate
4
Backside protection
The display surface should
be installed with the
projector positioned below
or above it, so that images
are projected upwards. In
this position, ambient light
is blocked from above,
leading to even higher im-
age contrast.
Subject to change without notice. Please check specification at time of ordering.
SIM2xTV Display Surfaces - leaflet - March 2017
*) Where 0° is perpendicular to display surface centre
(1)
Patents pending
