14
for the professional installer
2. Installation instructions
This unit may only be erected and electrically connected by a specialist following the installation
instructions.
First remove the packaging and check accessories and any enclosures, ensure that no accessories remain
in the packaging material.
2.1 Structure of unit
4 Air outlet grid
5 Wall bracket
6 Closing bolt
7 Mains connection cable
8 Rating plate
Technical data
Type WKL503S
WKL503U
WKL753S
WKL753U
WKL1003S
WKL1003U
WKL1503S
WKL1503U
WKL2003S
WKL2003U
WKL2503S
WKL2503U
WKL3003S
WKL3003U
Height mm 450
Width mm 370 445 445 590 740 890 1040
Depth
with wall bracket
mm
78
100
Dimension A mm 121 195 195 343 491 639 787
Weight kg 4,0 4,6 4,6 6,0 7,2 8,4 9,9
Connection 1/N ~ 230 V
Power kW 0,5 0,75 1,0 1,5 2,0 2,5 3,0
Temperature
adjustment range
ºC approx. 6 to 30
Frost protection ºC approx. 6
Protection class II
Protection mode IP 24, splash water protected
Approval see unit rating palte
2.2 Provisions and specification
The unit should not be operated
– inroomsatriskofexplosionorfirefromchemicals,dust,gasorvapour,
– intheimmediatevicinityofpipesorcontainerswhichtransportorcontainflammableor
explosive substances,
– iftheminimumdistancesfromadjacentobjectsurfacesarenotobserved.
In workshops or other rooms in which exhaust gases, oil or petrol vapours etc. occur or where solvents
and chemicals are used, persistent odour problems and where applicable contamination can occur.
The unit may only be fitted to a vertical wall, temperature-resistant up to at least 80 °C.
Minimum distances from adjacent object surfaces must be observed.
All electrical connection and installation work must be performed to VDE regulations (0100), the regula-
tions of a competent utility company and the corresponding national and regional regulations.
The unit must not be mounted directly below a wall socket.
If the unit is permanently connected to an AC network (junction box) an isolation distance of
at least 3mm is required on all poles for isolation from the network. For this, circuit breakers,
LS switches, fuses etc. can be used.
Installation with permanent connection cables is not permitted.
The rating plate must be observed. The rated voltage must correspond to the nominal voltage.
