Airwell Aelia II 7 IR [6/29] Accessories
![Airwell Aelia II 7 IR [6/29] Accessories](/views2/1408095/page6/bg6.png)
Models 3.1 KW (R407C)
Figure 3: Indoor and Outdoor Unit components Description (Back)
Models 3.1 KW (R407C) - With Quick Connectors
Models 4.1 KW (R22/R410A)
3.1 KW (R410A)
Models 4.1 KW (R22/R410A) - With Quick Connectors
3.1 KW (R410A) - With Quick Connectors
1. Quick disconnect cover (optional)
2. Key holes
3. Return air intake
4. Drain tube with plug-indoor unit
5. Air filter handle
6. Power Cord
7. Spacing stud holes
8. Drain tube with plug-outdoor unit
9. Castors outdoor unit (for model 4.1 KW,
3.1 KW /R410A)
10. Suspension bracket
11. Spacing studs
ACCESSORIES
1. Suction pads
2. Wrench no. 1
3. Wrench no. 2
Figure 4: Accessories
English 4
1
10
3
5
6
4
11
1
2
3
5
6
7
8
9
4
2
3
1
