Wespak 5.05
Руководство по обслуживанию Страница: 5

Airwell Wespak 5.05 [5/28] Basic modules

Airwell Wespak 4.05 [5/28] Basic modules

Page 5

Module HM0 Module HM1

Module HM2 Module HM3

Module HM9C External filter FA without casing

Module HM0 with diffusion section Module HM1 with diffusion section

Module HP0 Module HP1

Module HP2 Module HP3

Basic Modules

Horizontal Monobloc Units
