English REFRIGERANT CIRCUIT DIAGRAM SEE APPENDIX ACOUSTIC CAPACITY SPECTRUMS ACOUSTIC CAPACITY LEVEL SINGLE CIRCUIT MODEL 255 Sound power level by frequency band 305 405M Hz dB A dB A dB A 125 61 1 64 5 68 0 250 68 3 71 6 73 0 500 69 9 76 1 76 4 1000 76 9 77 4 77 7 2000 72 6 75 5 74 7 4000 69 4 68 4 74 1 80 82 83 Global DUAL CIRCUIT MODEL Sound power level by frequency band 405 505 605 755 905 Hz dB A dB A dB A dB A dB A 125 64 4 73 2 71 7 71 0 71 0 250 68 5 75 3 78 7 76 2 76 7 500 74 7 78 1 83 5 80 7 81 6 1000 78 3 79 4 81 0 80 7 81 0 2000 74 6 75 5 78 8 81 1 80 7 4000 72 8 69 2 71 2 75 6 77 6 82 84 87 87 87 Global OPERATING LIMITS Description Ambient air temperature C APPLICATION ADJUSTEMENT FACTOR ALTITUDE FACTORS Altitude m Cooling capacity Power input 600 0 987 1 01 1200 0 973 1 02 1800 0 958 1 029 2400 0 943 1 038 7 Mini Maxi 10 45
