Package

Levenhuk 2L NG

Microscope unit with stage, revolving head for three objectives,

focusing mechanism, two illuminations

1 Pc

Monocular nosepiece 1 Pc

Objectives: 4x, 10x and 40x 1 Pc each

Eyepiece WF16x 1 Pc

AC adapter 1 Pc

AA batteries 3 Pcs

User manual and warranty slip 1 Pc each

Levenhuk D2L NG

In addition to Levenhuk 2L NG: Levenhuk D2L digital camera:

Digital camera 1 Pc

USB cable 1 Pc

SETUP CD Levenhuk ToupView (auto setup guide, drivers,

software for image visualization, xation and processing)

1 Pc

Levenhuk 3L NG

In addition to Levenhuk 2L NG: Levenhuk K50 experiments kit:

Prepared slides 5 Pcs

Clean slides 5 Pcs

Flasks: with pitch, sea salt, yeast, brine shrimp 1 Pc each

Brine shrimp hatchery 1 Pc

Microtome 1 Pc

Forceps 1 Pc

"Attractive microscope. Scrutinizing the microcosm" user guide 1 Pc

Focusing mechanism located on the stand allows vertical movement of the stage. The stage is moved

by focusing knob. The total focusing value is at least 10mm.

Slide holders are xed on the stage surface. Diaphragm disk is attached to the lower part of the stage.

Revolving head holds the objectives; the objectives can be replaced by rotating the ring until it

reaches the xed position.

Objectives:

Linear magnication Numerical aperture

4 0.1

10 0.25

40 0.65

The 40x objective is equipped with a spring casing, which protects the frontal lens from contacting the

specimen during the focus adjusting.

Modules description and usage

Caution: Please refer to the specications table for the correct mains voltage and never attempt to

plug a 110V device into 220V outlet and vice versa without using a converter. Remember that mains

voltage in the U.S. and Canada is 110V and 220—240V in most European countries.
