![Airwell CWP-CO 30 [30/42] English](/img/pdf.png)
Airwell CWP-CO 30 [30/42] English
![Airwell CWP-CO 30 [30/42] English](/views2/1408677/page30/bg1e.png)
Page 29
English
Technical data
8.3 Electrical data
CWP/CWP-HP/CWP RC 02 03 04 05 06 07 09
Nominal voltage
V(%)/ph/Hz 4
00 ±10% / 3 / 50
Max power input kW 2.3 2.7 6.4 7.4 8.9 12.2 15.1
Max. current (FLA) A 17.3 6.5 12.0 13.0 15.1 20.7 26.0
Max. start-up current (LRA) A 76 46 66 74 99 127 168
CWP/CWP-HP/CWP RC 15 18 21 25 30 35
Nominal voltage
V(%)/ph/Hz 4
00 ±10% / 3 / 50
Max power input kW 16.4 24.2 28.1 32.9 44.5 56.2
Max. current (FLA) A 27.8 41.0 48.0 55.6 75.3 95.0
Max. start-up current (LRA) A 198 225 272 226 300 320
