Page 17
English
IInnssttaallllaattiioonn
4.6 Power supply
BBeeffoorree ccaarrrryyiinngg oouutt aannyy ooppeerraattiioonnss oonn tthhee
eelleeccttrriiccaall ssyysstteemm,, mmaakkee ssuurree tthhaatt tthhee uunniitt iiss
ddeeeenneerrggiisseedd..
IItt iiss iimmppoorrttaanntt tthhaatt tthhee aapppplliiaannccee iiss ggrroouunn--
ddeedd..
The company in charge of the installation
shall conform to the standards applicable to
outdoor electrical connections.
IItteellccoo--IInndduussttrryy mmaayy nnoott bbee hheelldd lliiaabbllee ffoorr aannyy ddaammaa--
ggee aanndd//oorr iinnjjuurryy ccaauusseedd bbyy ffaaiilluurree ttoo ccoommppllyy wwiitthh
tthheessee pprreeccaauuttiioonnss..
The unit conforms to EN 60204-1.
The following connections shall be provided:
I
A 3-phase and grounding connection for the
power supply circuit.
I
The electrical distribution system shall meet the
power absorbed by the appliance.
I
The disconnecting and magnetothermal switches
must be sized to control the starting current of the
unit.
I
The power supply lines and the insulation devices
must be designed in such a way that every line in-
dependent.
I
It is recommended to install differential switches,
to prevent any damage caused by phase drops.
I
The fans and compressors are supplied through
contactors controlled from the control panel.
I
Each motor is provided with an internal safety
thermal device and external fuses.
I
The power supply cables must be inserted into de-
dicated openings on the front of the unit, and the
will enter the electrical board through holes drilled
on the bottom of the board.
4.7 Electrical connections
TThhee uunniitt mmuusstt bbee iinnssttaalllleedd oonn ssiittee aaccccoorrddiinngg ttoo tthhee
MMaacchhiinneerryy DDiirreeccttiivvee ((9988//3377//EECC)),, tthhee LLooww VVoollttaaggee
DDii--
rreeccttiivvee ((7733//2233//EECC)),, tthhee EElleeccttrroommaaggnneettiicc IInntteerrffeerreennccee
DDiirreeccttiivvee ((8899//333366//EECC)) aanndd tthhee uussuuaall pprroocceeddu
urreess aanndd
ssttaannddaarrddss aapppplliiccaabbllee iinn tthhee ppllaaccee ooff iinnssttaallllaattiioonn.. TThhee
uunniitt mmuusstt nnoott bbee ooppeerraatteedd iiff iittss iinnssttaallllaattiioonn hhaass nnoott
bbeeeenn ccaarrrriieedd oouutt aaccccoorrddiinngg ttoo tthhee iinnssttrruuccttiioonnss pprroovvii--
ddeedd iinn tthhiiss mmaannuuaall..
TThhee ppoowweerr ssuuppppllyy lliinneess mmuusstt ccoonnssiisstt ooff iinnssuullaatteedd ccoopp--
ppeerr ccoonndduuccttoorrss,, ddiimmeennssiioonneedd ffoorr tthhee mmaaxxiimmuumm aabb--
ssoorrbbeedd ccuurrrreenntt..
Connection to terminals must be performed accor-
ding to the diagram of connections (User’s Terminal
Box) provided in this manual and according to the
wiring diagram which accompanies the unit.
Before connecting the power supply lines,
check that the available voltage value does
not exceed the range specified in the Elec-
tric Data (Chapter 8).
For 3-phase systems, check also that the unbalance
between the phases does not exceed 2%. To perform
this check, measure the differences between the vol-
tage of each phase couple and their mean value du-
ring operation. The maximum % value of these diffe-
rences (unbalance) must not exceed 2% of the mean
voltage.
If the unbalance is unacceptable, contact the Energy
Distributor to solve this problem.
Supplying the unit through a line whose un-
balance exceeds the permissible value will
automatically void the warranty.
DANGER
DANGER
VLS-eng.qxp 12-04-2007 14:43 Pagina 17
