Chillers ULTIMA FREECOOL
Chillers
Installation & Maintenance Manual : 903-125 IM E 05/04/A
11
Installation Data
WEIGHTS
STANDARD D UFC200D-8 UFC225D-8 UFC250D-8 UFC275D-8 UFC300D-8
Weight - Machine kg 3340 3360 3380 3480 3670
Weight - Operating kg 3940 3960 3980 4070 4310
QUIET DQ UFC200DQ-8 UFC225DQ-8 UFC250DQ-8 UFC275DQ-8 UFC300DQ-8
Weight - Machine kg 3270 3290 3310 3410 3600
Weight - Operating kg 3870 3890 3910 4000 4240
SUPER QUIET DSQ UFC200DSQ-8 UFC225DSQ-8 UFC250DSQ-8 UFC275DSQ-10 UFC300DSQ-10
Weight - Machine kg 3270 3290 3310 3780 3980
Weight - Operating kg 3870 3890 3910 4500 4750
STANDARD D UFC350D-10 UFC400D-10 UFC450D-12 UFC500D-12 UFC575D-14
Weight - Machine kg 4130 4170 4870 5000 5490
Weight - Operating kg 4890 4920 5860 5980 6570
QUIET DQ UFC350DQ-12 UFC400DQ-12 UFC450DQ-14 UFC500DQ-14 UFC575DQ-16
Weight - Machine kg 4410 4440 5170 5290 5760
Weight - Operating kg 5300 5320 6290 6390 6970
SUPER QUIET DSQ UFC350DSQ-14 UFC400DSQ-14 UFC450DSQ-16 UFC500DSQ-16 UFC575DSQ-18
Weight - Machine kg 4820 4850 5560 5690 6140
Weight - Operating kg 5840 5860 6810 6920 7480
STANDARD D UFC650D-14 UFC700D-18 UFC750D-18
Weight - Machine kg 5560 6630 7000
Weight - Operating kg 6690 7990 8450
QUIET DQ UFC650DQ-16 UFC700DQ-18 UFC750DQ-18
Weight - Machine kg 5830 6470 6840
Weight - Operating kg 7090 7830 8290
SUPER QUIET DSQ UFC650DSQ-18 UFC700DSQ-20 UFC750DSQ-20
Weight - Machine kg 6210 6860 7220
Weight - Operating kg 7600 8350 8800
