Description:
The pump is designed to collect condensated water
from Air Conditioning and Refrigeration Plant. The
pump is triggered by an internal float switch at a
factory set level, and discharge the condensate to
a recommended maximum head. The internal low
current safety float switch is pre-wired to give a
normally closed set of volt free contacts to enable
the plant to be switched off or an alarm to be
triggered in the event of pump failure.
Installation Notes:
This pump is designed to sit level on its base.
Ensure that there are no kinks or trapped parts in
the discharge piping, which must have an internal
diameter of 9mm.
Fix the pipes with cable ties to the pump inlet
and outlet.
IMPORTANT: The pre-wired safety switch MUST
ALWAYS be utilised.
Service Guide:
Flush the pump through with an anti-bacterial
wash every 6 months to avoid sludge build-up in
the pump housing.
NB: The contractors should satisfy themselves that
any chemicals used are compatible with the
working of the pump.
IMPORTANT: Pump should be filled with water
until motor runs, check for leaks and proper
discharge of water.
For further help contact Aspen Pumps.
GB
Technical Specification:
Q 2 metre connecting cable
Q Self-priming
Q Tank holds 4 litres
Q 4,0A pre-wired safety switch
Q Max. water temperature: 40°C
Q Non-return valve
Q 2 x 40mm ø inlets / 1 x 10mm ø outlet
Heavy Duty 6m:
Q Maximum discharge head: 6m
Q Maximum water pumping capacity
900 litres per hour discharge
Q Pump rating 1.5A, 230V AC, 110W
Heavy Duty 10m:
Q Maximum discharge head: 10m
Q Maximum water pumping capacity
1250 litres per hour discharge
Q Pump rating 0.49A, 230V AC, 150W
Dimensions:
6m: Height: 205mm Width: 300mm
Depth: 150mm Weight: 3.5kg
10m: Height: 265mm Width: 300mm
Depth: 150mm Weight: 4.3kg
Electrical Connections:
Brown: Live
Blue: Neutral
Green/yellow: Earth
2 x Black: Safety float switch
Heavy Duty
6m & 10m
Tank Pump
Particularly suitable for any
condition requiring the rapid
removal of condensate or
defrost water
PUMP
MOTOR
PUMP CASING
SAFETY
FLOAT SWITCH
NORMAL
FLOAT SWITCH
LIVE
EARTH
NEUTRAL
BLACK
BLACK
1400
1200
1000
800
600
400
200
0
024 6810
METRES HEAD
FLOW IN LITRES/HOUR
PERFORMANCE
6m
10m
