Asus PRIME B350M-K MB Pin Definition v2 онлайн
Motherboard Pin
Denition
1
E11133
Revised Edition v2
December 2015
E11133_MB_pin_definition_v2.indd 1 2015/12/28 17:21:46
Содержание
- Definition 1
- Motherboard pin 1
- Motherboard pin definition 1
- Contents 2
- Motherboard pin definition 1 1 2
- Headers 3
- Jumpers 4
- Internal connectors 6
- 12v dc 12v dc 12v dc 12v dc 7
- Atx power connectors 24 pin eatxpwr 8 pin eatx12v 4 pin eatx12v 7
- Gnd gnd gnd gnd 7
- Motherboard pin definition 7
- Single usb 2 connector 5 1 pin 7
- Speaker 7
- Speaker connector 4 pin speaker 7
- The 4 pin connector is for the chassis mounted system warning speaker the speaker allows you hear system beeps and warnings 7
- Theseconnectorsareforatxpowersupply plugs thepowersupplyplugsaredesignedtofit these connectors in only one orientation find the properorientationandpushdownfirmlyuntilthe connectorscompletelyfit 7
- This connector is for a usb 2 port connect the usb module cable to this connector then install the module to a slot opening at the back of the system chassis this usb connector complies with usb 2 specificationsandsupportsupto480mbpsconnectionspeed 7
- Digital audio connector 4 1 pin spdif_out 8
- Direct connector 2 pin drct 8
- E11133_mb_pin_definition_v2 indd 8 2015 12 28 17 21 47 8
- Ensure that your chassis comes with the button cable that supports the directkey feature refer to the technical documentation that came with the chassis for details 8
- Front panel audio connector 10 1 pin aafp 8
- Lpt connector 26 1 pin lpt 8
- Motherboard pin definition 8
- The lpt line printing terminal connector supports devices suchasaprinter lptstandardizesasieee1284 whichisthe parallel port interface on ibm pc compatible computers 8
- This connector is for a chassis mounted front panel audio i o module that supports either hd audio or legacy ac 97 audio standard connect one end of the front panel audio i o module cable to this connector 8
- This connector is for an additional sony philips digital interface s pdif port connect the s pdif out module cable to this connector then install the module to a slot opening at the back of the system chassis 8
- This connector is for the chassis mounted button that supports the directkey function connect the button cable that supports directkey from the chassis to this connector on the motherboard 8
- Werecommendthatyouconnectahigh definitionfront panel audio module to this connector to avail of the motherboard shigh definitionaudiocapability 8
- Chipset 9
- Edp back 9
- Embedded displayport 40 pin edp 9
- Enable lvds in the bios setup if the lvds output is disabled by default 9
- Floating device_reset gnd detection 9
- Gnd rsata_rxp4 rsata_rxn4 gnd rsata_txn4 rsata_txp4 gnd 9
- Gnd rsata_txp1 rsata_txn1 gnd rsata_rxn1 rsata_rxp1 gnd 9
- Gnd rsata_txp2 rsata_txn2 gnd rsata_rxn2 rsata_rxp2 gnd 9
- If you installed sata hard disk drives you can create a raid 0 1 5 and10configurationwiththeinte 9
- Lvds connector 40 pin lvds 9
- Motherboard pin definition 9
- Pin 1 pin 20 9
- Pin 40 pin 21 9
- Rapid storage technology through the onboard inte 9
- Sata 6 gb s connectors 7 pin sata6g 9
- Sata express connector 7 pin sata6g sataexpress 9
- Sata6g 9
- Thesataexpressconnectorcansupportonesataexpress device or two sata devices 9
- These connectors connect to sata 6 gb s hard disk drives via sata 6 gb s signal cables 9
- This connector connects to sata 6 gb s hard disk drives via sata 6 gb s signal cables 9
- This connector is for an internal embedded displayport connection 9
- This connector is for an lcd monitor that supports low voltage differential signaling lvds interface 9
- Xpservicepack3orlaterversionbefore using serial ata hard disk drives 9
- You must install window 9
- Desktop responsiveness technologies with pcie sata m device ensure to set up the window 13
- M socket 1 e key 13
- M socket 3 13
- Motherboard pin definition 13
- This connector supports a trusted platform module tpm system whichcansecurelystorekeys digitalcertificates passwords and data a tpm system also helps enhance network security protects digital identities and ensures platform integrity 13
- This connector supports a trusted platform module tpm system whichcansecurelystorekeys digitalcertificates passwords anddata a tpm system also helps enhance network security protects digital identities and ensures platform integrity 13
- This socket allows you to install an m e key wi fi and wi fi based combo device 13
- This socket allows you to install an m ngff ssd module 13
- Thissocketsupportsmkeyand2242 2260 2280 22110or 2242 2260 22110 storage devices by models 13
- Tpm connector 14 1 pin tpm 13
- Tpm connector 20 1 pin tpm 13
- Uefi operating system under raid mode 13
- Whenusinginte 13
- Custom header 14 pin custom 15
- Dmic connector 4 pin dmic 15
- E11133_mb_pin_definition_v2 indd 15 2015 12 28 17 21 48 15
- Motherboard pin definition 15
- The custom header is for connecting customized modules for additional features 15
- The dmic connector is for connecting the digital microphone module used in all in one chassis 15
- Onboard leds 16
- Installing dimms that are not compatible with the motherboard may cause system boot failure press the memok button until the memory compatibility tuning for successful boot 17
- Memok button memok 17
- Motherboard pin definition 17
- Onboard buttons and switches 17
- Onboardbuttonsallowyoutofine tuneperformancewhenworkingonabareoropen case system this is ideal for overclockers and gamers who continually change settings to enhance system performance 17
- Power on button start 17
- Press the reset button to reboot the system 17
- Reset button reset 17
- The motherboard comes with a power on button that allows you to power up or wake up the system the button also lights up when the system is plugged to a power source indicating that you should shut down the system and unplug the power cable before removing or installing any motherboard component 17
