Yamaha DVD-S796 [8/40] Before connections
![Yamaha DVD-S796 [8/40] Before connections](/views2/1041241/page8/bg8.png)
Getting Started
8
Home theater
º Settings for your Home Theater
¤1 If you have connected an AV amplifier with built-in Dolby Pro Logic decoder, you may need to connect center and rear speakers.
¤2 Connect speakers if necessary and make the speaker settings on the amplifier.
º Upgrading your television
³You can connect CRT projectors, LCD projectors, and projection televisions.
³See “Connection to a television” (á pages 12 and 13) for details on connection.
Note
³The equipment connections described are examples.
³Peripheral equipment and optional cables sold separately unless otherwise indicated.
º Before connections
³Ensure that this player and other equipment to be connected are switched to the standby mode or off and disconnect the AC power supply cord
before commencing connection.
³Do not block ventilation holes of any of the equipment and arrange them so that air can circulate freely.
³Read through the instructions before connecting other equipment.
³Ensure that you observe the color coding when connecting audio and video cables.
Note
³TV volume may be lower when playing DVDs than during television broadcasts. Turn the volume up while playing DVDs and reduce it to the
previous level before switching the source back to television to avoid sudden changes in volume.
³When you have finished connection, select the appropriate screen type at the initial setting “6 TV Aspect” according to your television (4:3/16:9)
(á page 31). No changes are needed if you connect the player to a conventional television (4:3).
Conserving power
³The unit consumes approx. 2.0 W even when it is turned off with [STANDBY/ON]. To save power when the unit is not to be used for a long time,
unplug it from the household AC outlet.
Set up
System
To enjoy 5.1 channel
surround sound
To enjoy Dolby surround
sound
¤1
To enjoy linear PCM sound
Equipment to be connected
AV amplifier with digital input and
built-in Dolby Digital/DTS decoder
AV amplifier with digital input and
built-in Dolby Digital decoder
(without DTS decoder)
AV amplifier with built-in Dolby
Pro Logic decoder
Stereo amplifier with digital input
and built-in high sampling DA
converter rated at 96 kHz
Stereo amplifier with digital input
and built-in conventional DA
converter
Speakers
³Main L/R
³Center
¤2
³Rear L/R¤2
³Subwoofer¤2
³Main L/R
³Center
¤2
³Rear L/R¤2
³Subwoofer¤2
³Main L/R
³Center
³Rear L/R
Main L/R
Main L/R
Settings in
“7 Digital Audio Output”
1. PCM down Conversion⇒“Yes”
2. Dolby Digital⇒“Bitstream”
3. DTS⇒“Bitstream”
1. PCM down Conversion⇒“Yes”
2. Dolby Digital⇒“Bitstream”
3. DTS⇒“Off”
1. PCM down Conversion⇒“Yes”
2. Dolby Digital⇒“PCM”
3. DTS⇒“Off”
1. PCM down Conversion⇒“No”
2. Dolby Digital⇒“PCM”
3. DTS⇒“Off”
1. PCM down Conversion⇒“Yes”
2. Dolby Digital⇒“PCM”
3. DTS⇒“Off”
Page
9
9
10
11
11
