Yamaha DVD-S700 [45/48] Self diagnosis display function
![Yamaha DVD-S700 [45/48] Self diagnosis display function](/views2/1041260/page45/bg2d.png)
45
Self-diagnosis display function
When an error or trouble is detected during operation, a service number appears in the display window.
When a service number has appeared, check out the details given below.
Service number
U11
H Å Å
Player status
Disc is dirty.
Trouble is likely to have occurred. The
number following “H” differs depending
on the status of the player.
Remedy
Wipe the disc clean.
Switch the power to the standby mode and then return to ON.
Alternatively, switch the power to the standby mode,
disconnect the AC mains lead and then re-connect it.
If the service number fails to be cleared even when the
remedial action is taken, ask for the service engineer to repair
the player.
Symptom [DVD] Remedy
Audio soundtrack and/or subtitle
language is not the one selected at the
initial settings.
The menu is displayed in French
(example).
Lightening and darkening of the picture.
No subtitles.
Alternative audio soundtrack (or subtitle)
languages fail to be selected.
Angle cannot be changed.
The password for age restriction has
been forgotten.
If the audio soundtrack and/or subtitle language does not exist on the disc, the
language selected at the initial settings will not be seen/heard.
The setup “Menus” of “Disc Languages” is set to French: select English.
Some discs will be copy protected at the direction of copyright owners. During
playback of those discs, picture may not be normally played back when video
signals containing a copy protected signal are played back through a VCR. It is
recommended to connect the DVD/Video CD/CD player directly to an AV amplifier
or to a TV set, not through a VCR.
ÁSubtitles appear only with discs which contain them.
ÁSubtitles are cleared from the TV monitor. Perform the steps on page 27 to display
the subtitles.
ÁAn alternative language is not selected with discs which do not contain more than
one language.
ÁIn the case of some discs, the alternative language cannot be selected by
operating the AUDIO or SUBTITLE button. Try selecting it from the DVD menu if
one is available.
This function is dependent on software availability. Even if a disc has a number of
angles recorded, these angles may be recorded for specific scenes only (when
“ANGLE” lights up on the FL display.)
While the unit is in the stop mode, hold the unit’s 0SKIP button and the STILL/
PAUSE button down simultaneously and then hold the POWER button down for
longer than 3 seconds (until “Initialized” disappears from the TV monitor). The lock
will be released and all initial settings will return to the default values.
Symptom [Video CD] Remedy
No menu play. This function works only for Video CDs with playback control.
