Yamaha DVD-C900 [5/74] About the symbols used in this manual
![Yamaha DVD-C900 [5/74] About the symbols used in this manual](/views2/1041344/page5/bg5.png)
1
English
●
5-Disc Carousel Auto-Changer (for
Playing DVDs, Video CDs and Compact
Discs)
●
Full Opening Disc Table for Changing
5 Discs at a Time
●
Compatible with Almost of All Utility
Functions of DVD Discs
●
PLAYXCHANGE; Disc Changing
Capability while Playing Another
●
Program Play
●
Random Play
●
Single Track/Full Disc Repeat Play and
A-B Repeat Play for Repeating a Section
between Two Specified Points
●
Multi-Speed Playback Capability
●
On Screen Display Function (Displays
This Unit’s Operation Status and Disc
Information on the TV Monitor)
●
SET UP Menu Which Provides You with
Various Changeable or Adjustable Items
for Using This Unit in the Most Suitable
Condition
●
1 OPTICAL and 1 COAXIAL Digital
Terminals to Output Digital Audio Signals
Encoded with Dolby Digital, DTS, MPEG
or Linear PCM
●
S VIDEO and COMPONENT VIDEO
Outputs for High-Quality Picture
Reproduction
●
Remote Control Capability
China and General models only
●
Built-in Dolby Digital Decoder to Provide
You with High-quality 5.1-channel
Surround Sound of Sources Encoded
with Dolby Digital
Features
About the symbols used in this manual
A section whose title has one of the following symbols is
applicable only to the disc represented by the symbol.
.............DVD
.............Video CD
.............CD
* A section with no symbol is applicable to all discs.
DVD
VCD
CD
Manufactured under license from Dolby Laboratories.
“Dolby” and the double-D symbol are trademarks of Dolby
Laboratories. Confidential Unpublished Works.
1992–1997 Dolby Laboratories, Inc. All rights reserved.
