![Sony KDL-26L4000 [44/75] Safety information](/views2/1041519/page44/bg2c.png)
8
GB
Safety information
Installation/Set-up
Install and use the TV set in accordance with the
instructions below in order to avoid any risk of fire,
electrical shock or damage and/or injuries.
Installation
• The TV set should be installed near an easily accessible
mains socket.
• Place the TV set on a stable, level surface.
• Only qualified service personnel should carry out wall
installations.
• For safety reasons, it is strongly recommended that you
use Sony accessories, including:
KDL-32L40xx:
– Wall-mount bracket SU-WL500
KDL-26L40xx:
– Wall-mount bracket SU-WL100
• Be sure to use the screws supplied with the Wall-mount
bracket when attaching the mounting hooks to the TV
set.
The supplied screws are designed so that they are 8 mm
to 12 mm in length when measured from the attaching
surface of the mounting hook.
The diameter and length of the screws differ depending
on the Wall-mount bracket model. Use of screws other
than those supplied may result in internal damage to the
TV set or cause it to fall, etc.
Transporting
• Before transporting the TV set, disconnect all cables.
• Two or more people are needed to transport a large TV
set.
• When transporting the TV set by hand, hold it as shown
below. Do not put stress on the LCD panel and the frame
around the screen.
• When lifting or moving the TV set, hold it firmly from
the bottom.
• When transporting the TV set, do not subject it to jolts
or excessive vibration.
• When transporting the TV set for repairs or when
moving, pack it using the original carton and packing
material.
Ventilation
• Never cover the ventilation holes or insert anything in
the cabinet.
• Leave space around the TV set as shown below.
• It is strongly recommended that you use a Sony wall-
mount bracket in order to provide adequate air-
circulation.
Installed on the wall
Installed with stand
Screw (supplied with the
Wall-mount bracket)
Mounting Hook
Hook attachment on rear of TV set
8-12 mm
30 cm
10 cm
10 cm
10 cm
Leave at least this space around the set.
30 cm
10 cm10 cm
6 cm
Leave at least this space around the set.
