TL-WDR4300 N750 Wireless Dual Band Gigabit Router
- 2 -
Chapter 1. Introduction
Thank you for choosing the TL-WDR4300 N750 Wireless Dual Band Gigabit Router.
1.1 Overview of the Router
The TL-WDR4300 N750 Wireless Dual Band Gigabit Router integrates 4-port Switch, Firewall,
NAT-Router and Wireless AP. Powered by 3x3 MIMO technology, the N750 Wireless Dual Band
Gigabit Router delivers exceptional range and speed, which can fully meet the need of Small
Office/Home Office (SOHO) networks and the users demanding higher networking performance.
Your wireless connections are radio band selectable to avoid interference in your area, and the four
built-in Gigabit ports supply high-speed connection to your wired devices.
Incredible Speed
The TL-WDR4300 N750 Wireless Dual Band Gigabit Router provides up to 300Mbps (2.4GHz) +
450Mbps (5GHz) wireless connection with other 802.11n wireless clients. The incredible speed makes
it ideal for handling multiple data streams at the same time, which ensures your network stable and
smooth. The performance of this 802.11n wireless Router will give you the unexpected networking
experience at speed much faster than 802.11g. It is also compatible with all IEEE 802.11g and IEEE
802.11b products.
Multiple Security Protections
With multiple protection measures, including SSID broadcast control and wireless LAN
64/128/152-bit WEP encryption, Wi-Fi Protected Access (WPA2- PSK, WPA- PSK), as well as
advanced Firewall protections, the TL-WDR4300 N750 Wireless Dual Band Gigabit Router
provides complete data privacy.
Flexible Access Control
The TL-WDR4300 N750 Wireless Dual Band Gigabit Router provides flexible access control, so
that parents or network administrators can establish restricted access policies for children or staff. It
also supports Virtual Server and DMZ host for Port Triggering, and then the network administrators
can manage and monitor the network in real time with the remote management function.
Simple Installation
Since the Router is compatible with virtually all the major operating systems, it is very easy to
manage. Quick Setup Wizard is supported and detailed instructions are provided step by step in
this user guide. Before installing the Router, please look through this guide to know all the
Router’s functions.
