Dell Vostro 3268-8176 [10/59] Installing the cooling shroud

Installing the cooling shroud

1 Align the tabs on the cooling shroud with the securing slots on the computer.

2 Lower the cooling shroud into the chassis until it is rmly seated.

3 Install the cover.

4 Follow the procedure in After Working Inside Your Computer.

Плата расширения

Removing the expansion card

1 Follow the procedure in Before working inside your computer.

2 Remove the cover.

3 Perform the following steps to remove the expansion card:

a Pull the metal tab to release the expansion card [1].

b Push the tab forward [2], and remove the expansion card from the slot on the computer [3].

10 Извлечение и установка компонентов
