Dell Vostro 3268-8176 [11/59] Installing the expansion card

Installing the expansion card

1 Insert the expansion card on the slot.

2 Push the card- retention latch to secure the expansion card.

3 Push the metal tab until it snaps in place.

4 Install the cover

5 Follow the procedure in After Working Inside Your Computer.

Жесткий диск

Removing the hard drive assembly

1 Follow the procedure in Before working inside your computer.

2 Remove the:

a cover

b bezel

c cooling shroud

3 Disconnect the power and the data cables from the hard drive.

NOTE: For easy access to the power and the data cables, it is recommended to remove the cooling shroud.

4 Follow the steps to remove the hard drive assembly:

a Remove the 6-32xL3.6 screws that secure the hard drive to the drive bay.

b Press the blue tab, and slide the hard drive from the hard drive bay.

Removing the hard drive from the hard drive bracket

1 Follow the procedures in Before Working Inside Your Computer.

2 Remove:

a cover

b front bezel

c cooling shroud

Извлечение и установка компонентов 11
