TL-WA7510N 5GHz 150Mbps Outdoor Wireless Access Point User Guide

¾ User Name/Password - Enter the User Name and Password provided by your ISP. These

fields are case-sensitive.

¾ Dynamic IP/ Static IP - Choose either as you are given by your ISP and enter the ISP’s IP

address or the domain name.

z If you choose static IP and enter the domain name, you should also enter the DNS

assigned by your ISP. And click the Save button.

z Click the Connect button to connect immediately. Click the Disconnect button to

disconnect immediately.

¾ Connect on Demand - You can configure the Device to disconnect from your Internet

connection after a specified period of inactivity (Max Idle Time). If your Internet connection

has been terminated due to inactivity, Connect on Demand enables the Device to

automatically re-establish your connection as soon as you attempt to access the Internet

again. If you wish to activate Connect on Demand, check the radio button. If you want your

Internet connection to remain active at all times, enter “0” in the Max Idle Time field.

Otherwise, enter the number of minutes you want to have elapsed before your Internet

connection terminates.

¾ Connect Automatically - Connect automatically after the Device is disconnected. To use this

option, check the radio button.

¾ Connect Manually - You can configure the Device to make it connect or disconnect manually.

After a specified period of inactivity (Max Idle Time), the Device will disconnect from your

Internet connection, and you will not be able to re-establish your connection automatically as

soon as you attempt to access the Internet again. To use this option, click the radio button. If

you want your Internet connection to remain active at all times, enter "0" in the Max Idle Time

field. Otherwise, enter the number in minutes that you wish to have the Internet connecting

last unless a new link is requested.

)

Note:

Sometimes the connection cannot be disconnected although you specify a time to Max Idle Time

because some applications are visiting the Internet continually in the background.

Click the Save button to save your settings.

6. If your ISP provides BigPond Cable (or Heart Beat Signal) connection, please select BigPond

Cable option. And then you should enter the following parameters as in Figure 5-22.

)

Note:

This type of WAN Connection is only available in AP Router mode, but not in AP Client Router

Mode.
