TD-W8970
3
00Mbps Wireless N Gigabit ADSL2+ Modem Router User Guide
102
Double-click Internet
Protocol Version 4
(TCP/IPv4)
Select Obtain an IP address
automatically
Select Obtain DNS server
address automatically
Click OK
