TD-W8970
3
00Mbps Wireless N Gigabit ADSL2+ Modem Router User Guide
103
For Windows 7 OS
Go to Start > Settings >
Control Panel, and then you
will see the following page.
Click Change adapter
settings
Click Properties
Right-click Local
Area Connection
Click View network
status and tasks
