TD-W8960N 300Mbps Wireless N ADSL2+ Modem Router User Guide

¾ Tunnel access from local IP addresses: Choose Subnet if you want the Whole LAN to join

the VPN network, or else choose Single Address if you want single IP to join the VPN network.

¾ IP Address for VPN: Enter the IP address of your LAN. (For example: Input 192.168.1.1 in

Device1, Input 192.168.2.1 in Device2)

¾ IP Subnetmask: Enter the Subnet mask of your LAN. ( For example: Input 255.255.255.0 in

both Device1 and Device2)

¾ Tunnel access from remote IP addresses: Choose Subnet if you want the Remote Whole

LAN to join the VPN network, or else choose Single Address if you want single IP to join the

VPN network.

¾ IP Address for VPN: Enter the IP address of the Remote LAN. ( For example: Input

192.168.2.1 in Device1,Input 192.168.1.1 in Device2)

¾ IP Subnetmask: Enter the subnetmask of the remote LAN. ( For example: Input

255.255.255.0 in both Device1 and Device2)

¾ Key Exchange Method: Select Auto (IKE) or Manual.

¾ Authentication Method: Select Pre-Shared Key (recommended).

¾ Pre-Shared Key: Input the Pre-Shared key for Authentication. (For example: Input 12345678)

¾ Perfect Forward Secrecy: PFS is an additional security protocol.

We recommend you leave the Advanced Settings as default value.

After complete the basic settings and click Save/Apply in both Device1 and Device2, PCs in LAN1

could conmmunicate with PCs in remote LAN2. (For example: You can ping the IP address of PC2

which is 192.168.2.100 in PC1)

)

Note:

The VPN Servers Endpoint from both ends must use the same pre-shared keys and Perfect

Forward Secrecy settings.

Click Show Advanced Settings and then you can configure the Advanced Settings.

¾ Main Mode: Select Main Mode to configure the standard negotiation parameters for IKE

phase1.
