Tp-Link TD-W8960N [65/110] Wireless

TD-W8960N 300Mbps Wireless N ADSL2+ Modem Router User Guide

4.5 Wireless

Choose “Wireless”, there are six submenus to configure Wireless LAN settings. Click any of them,

and you will be able to configure the corresponding function. The detailed explanations for each

submenu are provided below.

4.5.1 Basic

Choose “Wireless”Æ”Basic”, you will see the screen of Wireless--Basic settings shown as below.

The basic settings for wireless networking are set on this screen.

Figure 4-65

This page allows you to configure basic features of the wireless LAN interface. You can enable or

disable the wireless LAN interface, hide the network from active scans, set the wireless network

name (also known as SSID) and restrict the channel set based on Region requirements.

¾ Enable Wireless: If you want to use wireless features, you must select “Enable Wireless”. If

you deselect “Enable Wireless” option, all the Wireless settings below will be disabled.

¾ Hide SSID Broadcast: When wireless clients survey the local area for wireless networks to

associate with, you can select this option to avoided being surveyed.

¾ Clients Isolation: Select this option to enable AP isolation function so that stations associated

to the AP will not be able to communicate with each other.

¾ SSID: Wireless network name shared among all points in a wireless network. The SSID must

be identical for all devices in the wireless network. It is case-sensitive and must not exceed 32

characters (use any of the characters on the keyboard). Make sure this setting is the same for

all stations in your wireless network. Type the desired SSID in the space provided.

¾ BSSID: Show the MAC address of the Router.
