105
¾ Suggestion for Configuration
z Enable TC Protect function for all the ports of switches.
z Enable Root Protect function for all the ports of root bridges.
z Enable Loop Protect function for the non-edge ports.
Enable BPDU Protect function or BPDU Filter function for the edge ports which are connected to
the PC and server.
Return to CONTENTS
