02
Gigabit Unmanaged Switch
Front Panel
■
The front panel of TL-SG1048 is shown as the following figure.
Front Panel of Figure 1-1
TL-SG1048
The front panel of TL-SG1024 is shown as the following figure.
Front Panel of Figure 1-2
TL-SG1024
The front panel of TL-SG1024D is shown as the following figure.
Front Panel of Figure 1-3
TL-SG1024D
The front panel of TL-SG1016 is shown as the following figure.
Front Panel of Figure 1-4
TL-SG1016
The front panel of TL-SG1016D is shown as the following figure.
Front Panel of Figure 1-5
TL-SG1016D
Introduction
LEDs
10/100/1000Mbps RJ45 Port
LEDs
10/100/1000Mbps RJ45 Port
LEDs
10/100/1000Mbps RJ45 Port
LEDs
10/100/1000Mbps RJ45 Port
LEDs
10/100/1000Mbps RJ45 Port
